| Power |
| Total power |
600 W |
| AC input voltage |
100 - 240 V |
| Peak power |
650 W |
| AC input frequency |
50 - 60 Hz |
| Input current |
10 A |
| Power factor |
0.99 |
| Power Factor Correction (PFC) type |
Active |
| Combined power (+3.3V) |
110 W |
| Combined power (+12V) |
600 W |
| Combined power (+5V) |
110 W |
| Combined power (-12V) |
3.6 W |
| Combined power (+5Vsb) |
15 W |
| Max output current (+3.3V) |
22 A |
| Max output current (+12V) |
50 A |
| Max output current (+5V) |
22 A |
| Max output current (-12V) |
0.3 A |
| Max output current (+5Vsb) |
3 A |
| Hold time |
16.8 ms |
| Efficiency |
92% |
| Power protection features |
Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Weight & dimensions |
| Width |
125 mm |
| Depth |
130 mm |
| Height |
64 mm |
| Weight |
1.16 kg |
| Ports & interfaces |
| Motherboard power connector |
20+4 pin ATX |
| Motherboard power cable length |
30 cm |
| Number of SATA power connectors |
6 |
| Number of PATA power connectors |
3 |
| PCI Express power connectors (6+2 pin) |
4 |
| PCI Express power cable length |
40 cm |
| CPU power connector (4+4 pin) |
Yes |
| CPU power cable length |
40 cm |
| Cabling type |
Fully-Modular |
| Packaging data |
| Manual |
Yes |
| Package width |
205 mm |
| Package depth |
220 mm |
| Package height |
80 mm |
| Package weight |
2.04 kg |
| Package type |
Box |
| Other features |
| Screws included |
Yes |
| Cable ties included |
Yes |
| Noise level (silent mode, <30%) |
9.9 dB |
| Noise level (quiet mode, 50%) |
14.5 dB |
| Noise level (full-load mode, 100%) |
28.7 dB |
| Performance |
| Purpose |
PC |
| Power supply unit (PSU) form factor |
SFX |
| 80 PLUS certification |
80 PLUS Gold |
| Supported motherboard form factors |
Mini-ITX |
| ATX version |
2.4 |
| Silent mode |
Yes |
| Bearing technology |
Sleeve |
| Design |
| Product colour |
Black |
| Fan diameter |
12 cm |
| Number of fans |
1 fan(s) |
| On/off switch |
Yes |
| Logistics data |
| Master (outer) case width |
430 mm |
| Master (outer) case length |
430 mm |
| Master (outer) case height |
240 mm |
| Master (outer) case gross weight |
21.5 kg |
| Harmonized System (HS) code |
84733020 |
| Products per master (outer) case |
10 pc(s) |
| Technical details |
| Sustainability certificates |
ENERGY STAR |
| Certification |
| Compliance certificates |
RoHS |
| Certification |
CE, CB, TÜV, FCC, cTUVus, RCM |
