| Display |
| Display diagonal |
39.6 cm (15.6") |
| Display resolution |
1600 x 900 pixels |
| Touchscreen |
No |
| HD type |
HD+ |
| LED backlight |
Yes |
| Native aspect ratio |
16:9 |
| Processor |
| Processor family |
Intel® Core™ i5 |
| Processor manufacturer |
Intel |
| Processor model |
i5-430M |
| Processor frequency |
2.26 GHz |
| Processor generation |
4th gen Intel® Core™ i5 |
| Processor cores |
2 |
| Processor threads |
4 |
| Processor boost frequency |
2.53 GHz |
| System bus rate |
2.5 GT/s |
| Processor cache |
3 MB |
| Processor cache type |
Smart Cache |
| Processor socket |
BGA 1288 |
| Processor lithography |
32 nm |
| Processor operating modes |
64-bit |
| Processor series |
Intel Core i5-400 Series |
| Processor codename |
Arrandale |
| Bus type |
DMI |
| FSB Parity |
No |
| Stepping |
C2 |
| Thermal Design Power (TDP) |
35 W |
| Tjunction |
105 °C |
| Maximum number of PCI Express lanes |
16 |
| PCI Express slots version |
2.0 |
| PCI Express configurations |
1x16 |
| Number of Processing Die Transistors |
382 M |
| Processing Die size |
81 mm² |
| CPU multiplier (bus/core ratio) |
17 |
| ECC supported by processor |
No |
| Processore |
| Processor family |
Intel® Core™ i5 |
| Processor manufacturer |
Intel |
| Processor model |
i5-430M |
| Processor frequency |
2.26 GHz |
| Processor generation |
4th gen Intel® Core™ i5 |
| Processor cores |
2 |
| Processor threads |
4 |
| Processor boost frequency |
2.53 GHz |
| System bus rate |
2.5 GT/s |
| Processor cache |
3 MB |
| Processor cache type |
Smart Cache |
| Processor socket |
BGA 1288 |
| Processor lithography |
32 nm |
| Processor operating modes |
64-bit |
| Processor series |
Intel Core i5-400 Series |
| Processor codename |
Arrandale |
| Bus type |
DMI |
| FSB Parity |
No |
| Stepping |
C2 |
| Thermal Design Power (TDP) |
35 W |
| Tjunction |
105 °C |
| Maximum number of PCI Express lanes |
16 |
| PCI Express slots version |
2.0 |
| PCI Express configurations |
1x16 |
| Number of Processing Die Transistors |
382 M |
| Processing Die size |
81 mm² |
| CPU multiplier (bus/core ratio) |
17 |
| ECC supported by processor |
No |
| Connettività |
| USB 2.0 ports quantity |
4 |
| Ethernet LAN (RJ-45) ports |
1 |
| DisplayPorts quantity |
1 |
| DVI port |
No |
| VGA (D-Sub) ports quantity |
1 |
| Firewire (IEEE 1394) ports |
1 |
| Headphone outputs |
1 |
| S/PDIF out port |
No |
| Microphone in |
Yes |
| Charging port type |
DC-in jack |
| ExpressCard slot |
Yes |
| CardBus PCMCIA slot type |
No |
| SmartCard slot |
No |
| Ports & interfaces |
| USB 2.0 ports quantity |
4 |
| Ethernet LAN (RJ-45) ports |
1 |
| DisplayPorts quantity |
1 |
| DVI port |
No |
| VGA (D-Sub) ports quantity |
1 |
| Firewire (IEEE 1394) ports |
1 |
| Headphone outputs |
1 |
| S/PDIF out port |
No |
| Microphone in |
Yes |
| Charging port type |
DC-in jack |
| ExpressCard slot |
Yes |
| CardBus PCMCIA slot type |
No |
| SmartCard slot |
No |
| Memoria |
| Internal memory |
4 GB |
| Maximum internal memory |
8 GB |
| Internal memory type |
DDR3-SDRAM |
| Memory clock speed |
1333 MHz |
| Memory layout (slots x size) |
2 x 2 GB |
| Memory slots |
2x SO-DIMM |
| Memory |
| Internal memory |
4 GB |
| Maximum internal memory |
8 GB |
| Internal memory type |
DDR3-SDRAM |
| Memory clock speed |
1333 MHz |
| Memory layout (slots x size) |
2 x 2 GB |
| Memory slots |
2x SO-DIMM |
| Dimensioni e peso |
| Weight |
2.51 kg |
| Weight & dimensions |
| Weight |
2.51 kg |
| Gestione energetica |
| AC adapter power |
65 W |
| Power |
| AC adapter power |
65 W |
| Audio |
| Audio system |
HD |
| Built-in microphone |
Yes |
| Keyboard |
| Numeric keypad |
Yes |
| Pointing device |
Touchpad |
| Tastiera |
| Numeric keypad |
Yes |
| Pointing device |
Touchpad |
| Condizioni ambientali |
| Operating temperature (T-T) |
5 - 35 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 95% |
| Collegamento in rete |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Bluetooth |
Yes |
| Bluetooth version |
2.1+EDR |
| Networking |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Bluetooth |
Yes |
| Bluetooth version |
2.1+EDR |
| Security |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Sicurezza |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Operating system/software |
| Operating system installed |
Windows 7 Professional |
| Operating system architecture |
32-bit |
| Drivers included |
Yes |
| Software |
| Operating system installed |
Windows 7 Professional |
| Operating system architecture |
32-bit |
| Drivers included |
Yes |
| Archiviazione |
| Total storage capacity |
320 GB |
| Storage media |
HDD |
| Optical drive type |
DVD Super Multi DL |
| Number of HDDs installed |
1 |
| HDD capacity |
320 GB |
| HDD interface |
SATA II |
| HDD speed |
7200 RPM |
| Card reader integrated |
Yes |
| Compatible memory cards |
MMC, SD |
| Storage |
| Total storage capacity |
320 GB |
| Storage media |
HDD |
| Optical drive type |
DVD Super Multi DL |
| Number of HDDs installed |
1 |
| HDD capacity |
320 GB |
| HDD interface |
SATA II |
| HDD speed |
7200 RPM |
| Card reader integrated |
Yes |
| Compatible memory cards |
MMC, SD |
| Altre caratteristiche |
| LightScribe |
Yes |
| Infrared data port |
No |
| Graphics card family |
Intel |
| Dimensions (WxDxH) |
371.4 x 248 x 34.8 mm |
| Display |
TFT |
| Intel segment tagging |
Enterprise |
| Other features |
| LightScribe |
Yes |
| Infrared data port |
No |
| Graphics card family |
Intel |
| Dimensions (WxDxH) |
371.4 x 248 x 34.8 mm |
| Display |
TFT |
| Intel segment tagging |
Enterprise |
| Batteria |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Number of battery cells |
6 |
| Battery |
| Battery technology |
Lithium-Ion (Li-Ion) |
| Number of battery cells |
6 |
| Grafica |
| On-board graphics card |
Yes |
| Discrete graphics card |
No |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel® HD Graphics |
| On-board graphics card family |
Intel® HD Graphics |
| On-board graphics card base frequency |
500 MHz |
| On-board graphics card dynamic frequency (max) |
766 MHz |
| Graphics |
| On-board graphics card |
Yes |
| Discrete graphics card |
No |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel® HD Graphics |
| On-board graphics card family |
Intel® HD Graphics |
| On-board graphics card base frequency |
500 MHz |
| On-board graphics card dynamic frequency (max) |
766 MHz |
| Caratteristiche speciali del processore |
| Intel® Wireless Display (Intel® WiDi) |
No |
| Intel® My WiFi Technology (Intel® MWT) |
No |
| Intel® Anti-Theft Technology (Intel® AT) |
No |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® Turbo Boost Technology |
1.0 |
| Enhanced Intel SpeedStep Technology |
Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes |
| Intel Clear Video Technology |
Yes |
| Intel® InTru™ 3D Technology |
Yes |
| Intel® Insider™ |
Yes |
| Intel® Quick Sync Video Technology |
Yes |
| Intel Flex Memory Access |
Yes |
| Intel® Smart Cache |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
No |
| Intel Trusted Execution Technology |
No |
| Intel Enhanced Halt State |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Demand Based Switching |
No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) |
Yes |
| Intel 64 |
Yes |
| Execute Disable Bit |
Yes |
| Idle States |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Processor package size |
rPGA 37.5x 37.5, BGA 34x28 |
| Supported instruction sets |
SSE4.1, SSE4.2 |
| Processor code |
SLBPM |
| Physical Address Extension (PAE) |
36 bit |
| CPU configuration (max) |
1 |
| Embedded options available |
No |
| Graphics & IMC lithography |
45 nm |
| Intel Virtualization Technology for Directed I/O (VT-d) |
No |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Dual Display Capable Technology |
Yes |
| Intel FDI Technology |
Yes |
| Intel Rapid Storage Technology |
No |
| Intel Fast Memory Access |
Yes |
| Processor ARK ID |
43537 |
| Conflict-Free processor |
No |
| Processor special features |
| Intel® Wireless Display (Intel® WiDi) |
No |
| Intel® My WiFi Technology (Intel® MWT) |
No |
| Intel® Anti-Theft Technology (Intel® AT) |
No |
| Intel® Hyper Threading Technology (Intel® HT Technology) |
Yes |
| Intel® Turbo Boost Technology |
1.0 |
| Enhanced Intel SpeedStep Technology |
Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) |
Yes |
| Intel Clear Video Technology |
Yes |
| Intel® InTru™ 3D Technology |
Yes |
| Intel® Insider™ |
Yes |
| Intel® Quick Sync Video Technology |
Yes |
| Intel Flex Memory Access |
Yes |
| Intel® Smart Cache |
Yes |
| Intel® AES New Instructions (Intel® AES-NI) |
No |
| Intel Trusted Execution Technology |
No |
| Intel Enhanced Halt State |
Yes |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Intel Demand Based Switching |
No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) |
Yes |
| Intel 64 |
Yes |
| Execute Disable Bit |
Yes |
| Idle States |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Processor package size |
rPGA 37.5x 37.5, BGA 34x28 |
| Supported instruction sets |
SSE4.1, SSE4.2 |
| Processor code |
SLBPM |
| Physical Address Extension (PAE) |
36 bit |
| CPU configuration (max) |
1 |
| Embedded options available |
No |
| Graphics & IMC lithography |
45 nm |
| Intel Virtualization Technology for Directed I/O (VT-d) |
No |
| Intel Virtualization Technology (VT-x) |
Yes |
| Intel Dual Display Capable Technology |
Yes |
| Intel FDI Technology |
Yes |
| Intel Rapid Storage Technology |
No |
| Intel Fast Memory Access |
Yes |
| Processor ARK ID |
43537 |
| Conflict-Free processor |
No |
| Design |
| Product colour |
Black, Silver |
| Form factor |
Clamshell |
| Intel® vPro™ Platform Eligibility |
No |
| Country of origin |
China |
| Performance |
| Motherboard chipset |
Intel® HM57 Express |
| Prestazione |
| Motherboard chipset |
Intel® HM57 Express |
| Contenuto dell'imballo |
| AC adapter included |
Yes |
| Cables included |
AC |
| Packaging content |
| AC adapter included |
Yes |
| Cables included |
AC |
| Sustainability |
| Sustainability certificates |
ENERGY STAR |
