| Video |
| Supported video modes |
480p, 720p, 1080p |
| Supported graphics resolutions |
640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) |
| Aspect ratio |
16:10 |
| Video formats supported |
H.264, H.265, MJPG, YUY2 |
| Audio |
| Built-in speaker(s) |
Yes |
| Number of speakers |
4 |
| RMS rated power |
6 W |
| Operational conditions |
| Operating temperature (T-T) |
-10 - 50 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-10 - 60 °C |
| Weight & dimensions |
| Speaker dimensions (WxDxH) |
800 x 56 x 90 mm |
| Speaker weight |
3.6 kg |
| Camera dimensions (WxDxH) |
220 x 93.75 x 56.5 mm |
| Width |
240 mm |
| Depth |
200 mm |
| Height |
185.3 mm |
| Weight |
2.47 kg |
| Ports & interfaces |
| HDMI ports quantity |
3 |
| HDMI output ports quantity |
2 |
| HDMI input ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Headphone outputs |
1 |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
1000 Mbit/s |
| Wi-Fi |
Yes |
| Wi-Fi standards |
Wi-Fi 5 (802.11ac) |
| Power |
| Current |
1 A |
| Operating voltage (microphone) |
5 V |
| Display |
| Built-in display |
Yes |
| Display diagonal |
25.6 cm (10.1") |
| Display resolution |
1920 x 1080 pixels |
| Touchscreen |
Yes |
| Touchscreen type |
Capacitive |
| Display brightness |
320 cd/m² |
| Anti-glare screen |
Yes |
| Packaging content |
| Cables included |
USB |
| Remote control included |
Yes |
| Manual |
Yes |
| Memory |
| Internal memory |
8192 MB |
| Internal memory type |
DDR4 |
| Storage media type |
SSD |
| Total storage capacity |
128 GB |
| Camera |
| Sensor type |
CMOS |
| Image sensor size |
1/2.5" |
| Camera type |
Single camera |
| Zoom capability |
Yes |
| Digital zoom |
10x |
| Effective sensor resolution |
8.28 MP |
| Horizontal field of view |
120° |
| Vertical field of view |
85° |
| Diagonal field of view |
126° |
| Minimum illumination |
0.1 lx |
| Microphone |
| Microphone direction type |
Omnidirectional |
| Number of microphones |
4 |
| Features |
| Telepresence |
No |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Computer system |
| Processor family |
Intel® Core™ i5 |
| Processor generation |
8th gen Intel® Core™ i5 |
| Processor model |
i5-8365U |
| Operating system installed |
Windows 10 IoT Enterprise SAC |
| Windows operating systems supported |
Windows 10, Windows 7, Windows 8.1 |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina |
| Other operating systems supported |
Linux |
| Performance |
| Product type |
Multimedia congress terminal |
| Number of persons |
16 person(s) |
| Product colour |
Black |
| Bluetooth |
Yes |
| Bluetooth version |
5.0 |
| PTZ control |
Yes |
| System requirements |
| Minimum system requirements |
Intel Core 2 Duo |
| Minimum processor speed |
2.4 GHz |
| Minimum RAM |
2048 MB |
