| Image sensor |
| Sensor type |
CMOS |
| Number of sensors |
1 |
| Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") |
| Progressive scan |
Y |
| Lens system |
| Number of lenses |
1 |
| Zoom capability |
Y |
| Optical zoom |
3x |
| Maximum aperture number |
1.6 |
| Focal length range |
3 - 9 mm |
| Camera |
| Camera pan control |
Y |
| Camera tilt control |
Y |
| Minimum illumination |
0.01 lx |
| Viewing angle, horizontal |
114° |
| Viewing angle, vertical |
58° |
| Camera shutter speed |
1/66500 - 2 s |
| Video |
| Maximum resolution |
1920 x 1080 pixels |
| Total megapixels |
2 MP |
| Video compression formats |
H.264,H.265,M-JPEG,MPEG4 |
| Supported graphics resolutions |
160 x 90,1920 x 1080 (HD 1080) |
| Frame rate |
60 fps |
| Video streaming |
Y |
| Image quality adjustment |
Brightness, Contrast, Saturation, Sharpness |
| Privacy masking |
Y |
| Text caption overlay |
Y |
| Bit rate control |
Variable Bit Rate (VBR) |
| Audio |
| Audio system |
2-way |
| Audio formats supported |
AAC-LC,ADPCM,LPCM,PCM |
| Sample rate |
48 kHz |
| Audio detection |
Y |
| Networking |
| Ethernet LAN |
Y |
| Ethernet interface type |
Gigabit Ethernet |
| Networking standards |
IEEE 802.3af,IEEE 802.3at |
| Supported network protocols |
IPv4, IPv6 USGv6, HTTP, HTTPS , SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, MQTT |
| Quality of Service (QoS) support |
Y |
| Number of users |
8 user(s) |
| Streaming method |
Multicast |
| Security |
| Password protection |
Y |
| Video motion detection |
Y |
| Active tampering alarm |
Y |
| IP address filtering |
Y |
| Security algorithms |
802.1x RADIUS |
| HTTPS encryption |
Y |
| Temperature sensor |
Y |
| Alert notification type |
E-mail |
| Power |
| Power source type |
PoE |
| Power consumption (typical) |
7.7 W |
| Power consumption (max) |
12.95 W |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| Microphone in |
Y |
| Terminal block port |
Y |
| Operational conditions |
| Operating temperature (T-T) |
-40 - 60 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
10 - 100% |
| Storage relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
| Width |
132 mm |
| Depth |
260 mm |
| Height |
132 mm |
| Weight |
1 kg |
| Packaging content |
| Number of cameras |
1 |
| Mounting brackets included |
Y |
| Manual |
Y |
| Night vision |
| Night vision |
Y |
| Night vision distance |
40 m |
| LED type |
IR |
| Infra-red wavelength |
850 nm |
| Storage |
| Card reader integrated |
Y |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory |
512 MB |
| Design |
| Form factor |
Bullet |
| Mounting type |
Wall |
| Product colour |
Black, White |
| Housing material |
Aluminium, Polycarbonate |
| International Protection (IP) code |
IP66, IP67 |
| IK code |
IK10 |
| Fog proof |
Y |
| Performance |
| Type |
IP security camera |
| Connectivity technology |
Wired |
| PTZ control |
Y |
| PTZ modes |
Digital PTZ |
| Wide Dynamic Range (WDR) |
Y |
| Day/night mode |
Y |
| Infrared (IR) cut-off filter |
Y |
| Certification |
55032 Class A, EN 50121-4, IEC 62236-4, EN 55035, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, IEC/EN/UL 62368-1, IEC/EN/UL 60950-22, IS 13252, IEC 62471, IEC 60068 |
