| Design |
| Form factor |
Desktop |
| Product colour |
Black |
| LED indicators |
Yes |
| Features |
| Supported graphics resolutions |
800 x 600 (SVGA), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080) |
| Supported video modes |
720p, 1080p |
| Maximum frame rate |
60 fps |
| Number of simultaneously connected devices (max) |
32 |
| Security updates end date |
31/12/2026 |
| Networking |
| Wi-Fi standards |
Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi data rate (max) |
867 Mbit/s |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| Frequency band |
5 GHz |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Security algorithms |
128-bit AES, SSID, WPA2, WPA2-PSK |
| Maximum operating distance |
20 m |
| System requirements |
| Windows operating systems supported |
Yes |
| Mac compatibility |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Packaging content |
| AC adapter included |
Yes |
| Cables included |
HDMI |
| Quick start guide |
Yes |
| Power |
| Power source type |
DC |
| Output voltage |
12 V |
| Input current |
3 A |
| Power consumption (max) |
11 W |
| Ports & interfaces |
| Interface |
HDMI |
| HDMI input ports quantity |
1 |
| Number of HDMI outputs |
1 |
| HDMI version |
2.0 |
| USB 2.0 ports quantity |
1 |
| Micro-USB ports quantity |
2 |
| DC-in jack |
Yes |
| Antenna |
| Antenna type |
External |
| Antenna gain level (max) |
5 dBi |
| Antennas quantity |
4 |
| Weight & dimensions |
| Weight |
630 g |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Storage temperature (T-T) |
-10 - 60 °C |
| Storage relative humidity (H-H) |
5 - 90% |
