| Weight & dimensions |
| Display width |
1299 mm |
| Display depth |
78.7 mm |
| Display height |
769.8 mm |
| Display weight |
34.3 kg |
| Display |
| Display diagonal |
139.7 cm (55") |
| Display technology |
LCD |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
350 cd/m² |
| HD type |
4K Ultra HD |
| Touchscreen |
Yes |
| Panel type |
IPS |
| LED backlight |
Yes |
| Number of simultaneous touchpoints |
20 |
| Multi-touch |
Yes |
| Native aspect ratio |
16:9 |
| Contrast ratio (typical) |
1300:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Display number of colours |
1.07 billion colours |
| Pixel pitch |
0.315 x 0.315 mm |
| Display diagonal (metric) |
138.787 cm |
| Horizontal scan range |
30 - 140 kHz |
| Vertical scan range |
24 - 75 Hz |
| Supported graphics resolutions |
640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800, 1600 x 1200, 1920 x 1080 (HD 1080), 2048 x 1152, 2560 x 1440, 3840 x 2160 |
| Supported video modes |
480p, 576p, 720p, 1080i, 1080p, 2160p |
| Hardness |
3H |
| Native refresh rate |
60 Hz |
| RGB colour space |
NTSC |
| Colour gamut |
72% |
| Packaging data |
| Package weight |
41.9 kg |
| Audio |
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Speaker impedance |
8 Ω |
| Speaker frequency range |
120 - 20000 Hz |
| Power |
| Power consumption (typical) |
77.1 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (off) |
0.3 W |
| Power consumption (max) |
320 W |
| Energy efficiency class (SDR) |
F |
| Energy efficiency class (HDR) |
Not available |
| Energy consumption (SDR) per 1000 hours |
77 kWh |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Heat dissipation |
263.08 BTU/h |
| Energy efficiency scale |
A to G |
| Ports & interfaces |
| HDMI ports quantity |
3 |
| DVI port |
No |
| DisplayPorts quantity |
1 |
| USB port |
Yes |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| HDMI version |
2.0 |
| USB ports quantity |
8 |
| USB version |
2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB connector type |
USB Type-A |
| USB 2.0 Type-B ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB Power Delivery |
Yes |
| USB Power Delivery up to |
90 W |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Audio (L/R) in |
1 |
| RS-232 interface |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
5 - 90% |
| Operating altitude |
0 - 5000 m |
| Non-operating altitude |
0 - 12192 m |
| Other features |
| Quick start guide |
Yes |
| Cable lock slot |
Yes |
| LED indicators |
Yes |
| On/off switch |
Yes |
| Viewable size, horizontal |
121 cm |
| Viewable size, vertical |
68 cm |
| Power supply type |
Internal |
| Cable management |
Yes |
| Response time |
9 s |
| Plug and Play |
Yes |
| Design |
| Product design |
Interactive flat panel |
| Product colour |
Black |
| Placement supported |
Indoor |
| VESA mounting |
Yes |
| Screen shape |
Flat |
| Panel mounting interface |
300 x 400 mm |
| Bezel width (bottom) |
4.47 cm |
| Bezel width (side) |
4.47 cm |
| Bezel width (top) |
4.47 cm |
| Anti-glare screen |
Yes |
| Performance |
| Purpose |
Corporate |
| On Screen Display (OSD) |
Yes |
| Technical details |
| Sustainability certificates |
ENERGY STAR |
| Doesn't contain |
Arsenic, Mercury, PVC/BFR |
| Compliance certificates |
RoHS |
| Sustainability compliance |
Yes |
| Computer system |
| Windows operating systems supported |
Windows 7 Professional, Windows 7 Ultimate, Windows 8, Windows 8.1 |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan |
| Linux operating systems supported |
Yes |
| Features |
| Heat dissipation (max) |
1091.89 BTU/h |
| Packaging content |
| Remote control included |
Yes |
| Stylus pen |
Yes |
| Number of stylus pens |
2 |
| Cables included |
DisplayPort, HDMI, USB, USB Type-C |
