| Weight & dimensions |
| Weight |
5.8 kg |
| Width |
367 mm |
| Depth |
400 mm |
| Height |
187 mm |
| Package width |
490 mm |
| Package depth |
740 mm |
| Package height |
335 mm |
| Package weight |
21.6 kg |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
-10 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Projector |
| Projector brightness |
3500 ANSI lumens |
| Projection technology |
3LCD |
| Projector native resolution |
WXGA (1280x800) |
| Contrast ratio (typical) |
300:1 |
| Native aspect ratio |
16:10 |
| Screen size compatibility |
1524 - 2540 mm (60 - 100") |
| Supported aspect ratios |
16:10 |
| Projection distance (wide) |
0 - 0.4 m |
| Projection distance (tele) |
0 - 0.6 m |
| Contrast ratio (dynamic) |
14000:1 |
| Number of colours |
1.073 billion colours |
| Projector brightness (economic mode) |
2900 ANSI lumens |
| Keystone correction, vertical |
±3° |
| Matrix size |
1.5 cm (0.59") |
| Vertical synchronization (min) |
0.1 kHz |
| Vertical synchronization (max) |
0.12 kHz |
| White light output |
3500 ANSI lumens |
| Colour light output |
3500 ANSI lumens |
| Video |
| Full HD |
No |
| 3D |
No |
| Video processing |
10 bit |
| Display |
| Built-in display |
No |
| Lens system |
| Focus |
Manual |
| Zoom ratio |
1.35:1 |
| Digital zoom |
1.35x |
| Throw ratio |
0.28:1 |
| Power |
| Power source |
AC |
| Power consumption (typical) |
356 W |
| Power consumption (standby) |
0.39 W |
| Power consumption (economy mode) |
312 W |
| AC input voltage |
220 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Ports & interfaces |
| VGA (D-Sub) ports quantity |
3 |
| HDMI ports quantity |
3 |
| Composite video in |
1 |
| DVI port |
No |
| USB 2.0 ports quantity |
3 |
| Audio (L/R) in |
1 |
| Serial interface type |
RS-232C |
| S-Video inputs quantity |
1 |
| Headphone outputs |
1 |
| Microphone in |
Yes |
| AC (power) in |
Yes |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Storage |
| Card reader integrated |
No |
| Packaging content |
| Remote control included |
No |
| Manual |
Yes |
| Other features |
| RS-232 ports |
1 |
| RS-232C |
Yes |
| Design |
| Product type |
Ultra short throw projector |
| Product colour |
Grey, White |
| Placement |
Wall |
| LED indicators |
Yes |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Multimedia |
| Built-in speaker(s) |
Yes |
| RMS rated power |
16 W |
| Software |
| Windows operating systems supported |
Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 |
| Mac compatibility |
Yes |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Linux operating systems supported |
Yes |
| Features |
| Country of origin |
Philippines |
| Light source |
| Light source type |
Lamp |
| Service life of light source |
5000 h |
| Service life of light source (economic mode) |
10000 h |
| Lamp power |
250 W |
| Logistics data |
| Quantity per pack |
1 pc(s) |
| Products per pallet |
12 pc(s) |
| Pallet gross length |
120 cm |
| Pallet gross width |
80 cm |
| Pallet gross height |
15 cm |
| Products per pallet layer |
2 pc(s) |
| Products per pallet layer (UK) |
2 pc(s) |
| Products per pallet (UK) |
12 pc(s) |
| Pallet length (UK) |
120 cm |
| Pallet width (UK) |
100 cm |
| Pallet height (UK) |
15 cm |
