Stock Status: 1x unit in stock
Continuously emulates HDMI EDID information
Supports resolutions up to 3840x2160@30Hz including HDCP pass-through
For use with 32120 for cloning
Powered via HDMI Source Interface
2 Year warranty
The Lindy HDMI 10.2G EDID Emulator Adapter is designed for systems that require EDID signals to be continuously provided without interruption and helps overcome EDID related problems which can occur when using AV/KVM extenders, switches and splitters. It can also be used in place of a monitor to keep the graphics card of a PC or server awake for remote access via IP. With support for resolutions up to 2160p including the ability to pass–through HDCP content, the Emulator is suitable for use with a wide variety of PC and AV applications. When used with the Lindy HDMI / VGA / DVI EDID Recorder (32120) this compact device can provide cloned EDID information to your graphics card.
It is also possible to use the Emulator without cloning a display as it comes complete with preset EDID data for the most commonly used resolution/timing combinations, please see the Technical Information section for a full breakdown.
Please note: This Emulator does not support HDMI 2.0 or HDCP 2.2 content. If you require this then please see our complete range of EDID emulators
Specs
| Ports & interfaces |
| Connector 1 |
HDMI-A |
| Connector 2 |
HDMI-A |
| Connector 1 gender |
Male |
| Connector 2 gender |
Female |
| Packaging data |
| Package width |
136 mm |
| Package height |
138 mm |
| Package type |
Polybag |
| Weight & dimensions |
| Width |
24 mm |
| Depth |
43 mm |
| Height |
12.3 mm |
| Weight |
8 g |
| Operational conditions |
| Operating temperature (T-T) |
0 - 60 °C |
| Storage temperature (T-T) |
-10 - 70 °C |
| Relative humidity |
0 - 80% |
| Packaging content |
| Manual |
Y |
| Performance |
| Product colour |
Black |
| Housing material |
Acrylonitrile butadiene styrene (ABS) |
| Data transfer rate |
18 Gbit/s |
| Maximum resolution (HDMI) |
3840 x 2160 pixels |
| Certification |
REACH, CE, FCC |
| Compatible products |
Lindy 32100 |
| Sustainability |
| Sustainability certificates |
RoHS |
Features
Lindy HDMI 10.2G EDID Emulator. Connector 1: HDMI-A, Connector 2: HDMI-A. Product colour: Black
Product Description
Continuously emulates HDMI EDID information
Supports resolutions up to 3840x2160@30Hz including HDCP pass-through
For use with 32120 for cloning
Powered via HDMI Source Interface
2 Year warranty
The Lindy HDMI 10.2G EDID Emulator Adapter is designed for systems that require EDID signals to be continuously provided without interruption and helps overcome EDID related problems which can occur when using AV/KVM extenders, switches and splitters. It can also be used in place of a monitor to keep the graphics card of a PC or server awake for remote access via IP. With support for resolutions up to 2160p including the ability to pass–through HDCP content, the Emulator is suitable for use with a wide variety of PC and AV applications. When used with the Lindy HDMI / VGA / DVI EDID Recorder (32120) this compact device can provide cloned EDID information to your graphics card.
It is also possible to use the Emulator without cloning a display as it comes complete with preset EDID data for the most commonly used resolution/timing combinations, please see the Technical Information section for a full breakdown.
Please note: This Emulator does not support HDMI 2.0 or HDCP 2.2 content. If you require this then please see our complete range of EDID emulators
