Stock Status: 1x unit in stock
Devices with no native wireless support can be easily integrated into a wireless LAN (WLAN) using the HP 501 Wireless Client Bridge. The HP 501 Wireless Client Bridge can bridge up to 15 Ethernet client device running a legacy networking protocol to the WLAN, extending wireless network access to a wide range of protocols. An integrated serial to TCP/IP converter enables a RS-232 asynchronous terminal device to communicate with a compatible station on the network. Strong enterprise-class layered security features, including an IEEE 802.1X supplicant, protect the network from intrusions. Hardware-accelerated encryption provides high performance when using WPA2/AES security. It enables organizations to unwire a broad range of computing devices and realize the benefits of mobility. Electronic cash registers, scales, servers, printers, medical equipment, manufacturing machinery and other devices can be deployed in any location where a WLAN signal is available, eliminating the time and expense of installing Ethernet cable for network access. The HP 501 Wireless Client Bridge integrates into the HP Mobility System and it is interoperable with any IEEE 802.11b/g/n or 802.11a/n/ac WLAN network infrastructure from HP or any other vendor.
Specs
| Weight & dimensions |
| Width |
139.7 mm |
| Depth |
33 mm |
| Height |
127 mm |
| Weight |
2 kg |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| Internal RJ-45 ports quantity |
1 |
| RS-232 interface |
Y |
| DC-in jack |
Y |
| Power |
| Power over Ethernet (PoE) |
Y |
| Power consumption (max) |
9 W |
| Power supply |
11 W |
| Other features |
| Antenna |
Three RP-SMA; 2 dBi dual-band omnidirectional; 3 external antennas |
| I/O ports |
1 RJ-45 autosensing 10/100/1000 port (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T);Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only; 1 RS-232C serial console port; Included |
| Antenna |
| Antennas quantity |
3 |
| Antenna gain level (max) |
2 dBi |
| Design |
| Product colour |
Grey |
| Internal |
Y |
| Features |
| 2.4 GHz |
Y |
| 5 GHz |
Y |
| Maximum data transfer rate |
1200 Mbit/s |
| Wi-Fi data rate (max) |
1300 Mbit/s |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Bandwidth |
5 GHz |
| Networking standards |
IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Operating modes |
Auto |
Features
Hewlett Packard Enterprise 501 Wireless Client Bridge. Maximum data transfer rate: 1200 Mbit/s, Wi-Fi data rate (max): 1300 Mbit/s, Ethernet LAN data rates: 10,100,1000 Mbit/s. Power consumption (max): 9 W, Power supply: 11 W. Product colour: Grey. Antenna gain level (max): 2 dBi. Width: 139.7 mm, Depth: 33 mm, Height: 127 mm
Product Description
Devices with no native wireless support can be easily integrated into a wireless LAN (WLAN) using the HP 501 Wireless Client Bridge. The HP 501 Wireless Client Bridge can bridge up to 15 Ethernet client device running a legacy networking protocol to the WLAN, extending wireless network access to a wide range of protocols. An integrated serial to TCP/IP converter enables a RS-232 asynchronous terminal device to communicate with a compatible station on the network. Strong enterprise-class layered security features, including an IEEE 802.1X supplicant, protect the network from intrusions. Hardware-accelerated encryption provides high performance when using WPA2/AES security. It enables organizations to unwire a broad range of computing devices and realize the benefits of mobility. Electronic cash registers, scales, servers, printers, medical equipment, manufacturing machinery and other devices can be deployed in any location where a WLAN signal is available, eliminating the time and expense of installing Ethernet cable for network access. The HP 501 Wireless Client Bridge integrates into the HP Mobility System and it is interoperable with any IEEE 802.11b/g/n or 802.11a/n/ac WLAN network infrastructure from HP or any other vendor.
