| Printing |
| Print speed (black, normal quality, A4/US Letter) |
35 ppm |
| Maximum resolution |
1200 x 1200 DPI |
| Print speed (black, draft quality, A4/US Letter) |
35 ppm |
| Standard printer languages |
PCL 5,PCL 6,PDF 1.4 |
| Print speed (black, normal quality, A3) |
18 ppm |
| Time to first page (black, normal) |
10 s |
| Warm-up time |
158 s |
| Print speed (black, best quality, A4) |
35 ppm |
| Print speed (black, best quality, A3) |
18.5 ppm |
| Print speed (black, draft quality, A3) |
18 ppm |
| Print speed (black, best quality, letter) |
Up to 35 ppm |
| Printing |
Mono printing |
| Duplex printing |
Y |
| Input capacity |
| Standard input capacity |
1100 sheets |
| Maximum input capacity |
2100 sheets |
| Maximum input capacity for envelopes |
Up to 10 envelopes |
| Paper handling |
100-sheet multi-purpose tray, two 250-sheet input trays, 500-sheet input tray with storage cabinet, 50-sheet two-sided reversing Automatic Document Feeder (ADF), automatic two-sided printing, 250-sheet output bin |
| Output capacity |
| Standard output capacity |
250 sheets |
| Maximum output capacity |
250 sheets |
| Standard output capacity for envelopes |
25 sheets |
| Weight & dimensions |
| Weight |
93 kg |
| Package weight |
100 kg |
| Width |
743 mm |
| Depth |
743 mm |
| Height |
997 mm |
| Scanning |
| Optical scanning resolution |
600 x 600 DPI |
| Scan type |
Flatbed |
| Input colour depth |
30 bit |
| Gray scale levels |
256 |
| Scan input modes |
Front-panel scan, copy, fax, e-mail, ADF |
| Scanner features |
Colour scanning of up to A3-size documents, 50-page ADF |
| Scan speed (black, normal quality) |
Up to 35 ppm |
| Scan speed (colour, normal quality) |
Up to 23 ppm |
| Minimum scan size |
27.9 x 43.2 cm |
| Send to other application |
Network folder |
| Send to email (Digital Sender) |
Y |
| Scanner type |
Flatbed scanner |
| Greyscale levels |
256 |
| Scanning |
Colour scanning |
| Copying |
| Maximum copy resolution |
600 x 600 DPI |
| Maximum number of copies |
1000 copies |
| Copy resolution (black graphics) |
Up to 600 x 600 dpi |
| Copy speed (best quality, black, A4) |
35 cpm |
| Left metric copy margin |
5 mm |
| Right metric copy margin |
5 mm |
| Top metric copy margin |
6 mm |
| Copier settings |
Sides, staple collate, image adjustment, reduce/enlarge, paper selection, content orientation, output bin, pages per sheet, booklet format, optimize text/picture, original size, job build, edge to edge |
| Bottom copy margin |
6 mm |
| Maximum copy speed (black, A4) |
35 cpm |
| Copy speed (black, best, letter) |
Up to 35 cpm |
| Time to first copy (letter) |
12 sec |
| Copying |
Mono copying |
| Fax |
| Modem speed |
33.6 Kbit/s |
| Auto-redialing |
Y |
| Fax broadcasting |
100 locations |
| Fax delayed sending |
N |
| Fax speed dialing (max numbers) |
100 |
| Auto reduction |
Y |
| Fax forwarding |
Y |
| Distinctive ring |
N |
| Telecom compliance (fax capability) |
Telecom: TBR-21:1998; EG 201 121:1998, FCC Part 68, Industry Canada CS03, NOM-151-SCTI-1999 (Mexico), PTC-200 (New Zealand), AS/ACIF S002:2001 (Australia), IDA PSTN1 (Singapore), TPS002-01 (Malaysia), IG 0005-11 (Taiwan), HKTA 2011 (Hong Kong), YD514, YD/ |
| Fax resolution black photo grayscale |
200 x 200 dpi |
| Fax resolution standard mode (black & white) |
200 x 200 dpi |
| Fax resolution superfine mode (black & white) |
Up to 300 x 300 dpi |
| Faxing |
Colour faxing |
| Operational conditions |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
13 - 38 °C |
| Operating temperature (T-T) |
50 - 99 °F |
| Storage relative humidity (H-H) |
20 - 80% |
| Recommended operating temperature range (T-T) |
15 - 35 °C |
| Operating altitude (imperial) |
10000 ft |
| Paper handling |
| Media weight (tray 1) |
60 to 199 g/m² |
| Auto Document Feeder (ADF) media weight |
60 to 120 |
| Duplex media weight |
60 - 120 g/m² |
| Envelope feeder |
N |
| Media handling |
Sheetfed |
| Maximum paper trays |
6 |
| Paper handling optional/input |
Optional 3x 500-sheet paper trays |
| Paper handling standard/input |
Two 250-sheet input trays standard, 100-sheet multi-purpose tray, 500-sheet input tray |
| Paper handling standard/output |
250-Sheet Output Bin |
| Media type and capacity (tray 2) |
Sheets: 250 |
| Media type and capacity (tray 3) |
Sheets: 250 |
| Paper handling |
100-sheet multi-purpose tray, two 250-sheet input trays, 500-sheet input tray with storage cabinet, 50-sheet two-sided reversing Automatic Document Feeder (ADF), automatic two-sided printing, 250-sheet output bin |
| Maximum print size |
307.9 x 465.9 mm |
| Networking |
| Supported network protocols (IPv4) |
IPv6: DHCPv6, HTTP, HTTPS, Port 9100, LPD, IIP, Secure IIP, MLDv6, ICMPv6; IPv4: FTP, IPP, Secure IPP, Auto-IP, Apple Bonjour compatible, Telnet, SLP, IGVPv2, BOOTP/DHCP, WINS, SNMPv1/v2c/v3, TFTP, HTTP, HTTPS, Port9100, LPD; Other: IPX/SPX, DLC, LLC, App |
| System requirements |
| Minimum system requirements |
133 MHz processor or higher, 64 MB RAM, 40 MB available hard disk space, USB or network port connection |
| Storage |
| Internal memory |
256 MB |
| Internal storage capacity |
40 GB |
| Packaging data |
| Package weight |
100 kg |
| Package width |
900 mm |
| Package depth |
900 mm |
| Package height |
1418 mm |
| Certificates |
| Energy Star certified |
Y |
| Electromagnetic compatibility |
CISPR 22:1993/EN 55022:1994 Class A, EN 61000-3-2:2000, EN 61000-3-3:1995, EN 55024:1998, FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, and carries the CE |
| Operating system/software |
| Copier smart software features |
Up to A3 capable copying on the glass and through the automatic document feeder, 50 page ADF, duplexing (optional), reduce/enlarge, contrast adjustments, mixed originals support, stapling on xs bundle |
| Printer smart software features |
Up to A3 capable printing, full HP LaserJet printing functionality, HP ProRes 1200 at full engine speed, duplexing available, Instant-on Technology, HP Smart printing technology |
| Downloadable software |
Printing system, PCL 6 driver only, PCL 5 driver only, PS driver only, WJA applet, UPD PCL 5, UPD PS, HP Easy Printer Care Software, PC fax driver |
| SureSupply software driver |
Y |
| Software |
| Copier smart software features |
Up to A3 capable copying on the glass and through the automatic document feeder, 50 page ADF, duplexing (optional), reduce/enlarge, contrast adjustments, mixed originals support, stapling on xs bundle |
| Printer smart software features |
Up to A3 capable printing, full HP LaserJet printing functionality, HP ProRes 1200 at full engine speed, duplexing available, Instant-on Technology, HP Smart printing technology |
| Downloadable software |
Printing system, PCL 6 driver only, PCL 5 driver only, PS driver only, WJA applet, UPD PCL 5, UPD PS, HP Easy Printer Care Software, PC fax driver |
| SureSupply software driver |
Y |
| Other features |
| Standard input trays |
4 |
| Networking features |
Via HP Jetdirect embedded networking, HP Jetdirect internal print servers, HP Jetdirect external print servers, HP wireless print servers, and HP connectivity cards |
| Dimensions (WxDxH) |
743 x 743 x 997 mm |
| Network ready |
Y |
| Power requirements |
Input voltage 220 to 240 VAC (+/- 10%), 50 Hz (+/- 2 Hz), 6 amp |
| Power supply type |
110/200V |
| Modem type |
33.6 Kbps |
| Media types supported |
Paper (plain, photo, banner), envelopes, labels, cards (index, greeting), transparencies, letter, pre-punched, recycled |
| Standard output capacity for transparancies |
200 sheets |
| Scan file formats |
JPG,PDF,TIFF |
| Safety |
Argentina (TÜV S Mark-Rs.92/98/Ds.1009/98), Australia (AS/NZ 3260), Canada (cUL-CAN/CSA C22.2 No.60950-1-03), China (GB4943), Czech Republic (CSN-IEC 60950-1; IEC 60825-1), Estonia (EEI-EN60950-1; IEC 60825-1), EU (CE Mark-Low Voltage Directive 73/23/EEC) |
| Compatible operating systems |
Microsoft Windows 2000, XP Home, XP Professional, XP Professional x64, Server 2003; Windows Vista supported soon (visit /go/windowsvista for more information); Mac OS X v 10.2 or higher |
| Functions |
Print, copy, send-to email/network folder, fax |
| Size |
90 cm (35.4") |
| Maximum scan area (ADF) |
297 x 432 mm |
| Minimum scan area (ADF) |
138 x 210 mm |
| All-in-one functions |
Fax, Scan |
| Colour all-in-one functions |
Fax, Scan, N |
| Package dimensions (WxDxH) |
900 x 900 x 1418 mm |
| Media size (tray 1) |
67.2 x 127 mm postcards, A5, A4, A3, B4, B5, EXE, LTR, LGL, LGR, 76 x 127 mm to 312 x 469.9 mm |
| I/O ports |
1 Hi-Speed USB 2.0; 1 LAN; 1 EIO; 1 FIH; 1 Host USB 2.0; 1 Analog Fax |
| Acoustic power emissions |
6.6 B(A) (printing at 35 ppm) |
| Duplex print options |
Automatic (standard) |
| Media weights by paper path |
Tray 1: 60 to 199 g/m²; Additional input trays and output finishing devices: 60 to 120 g/m²; Automatic document feeder: 60 to 120 g/m² |
| Pallet dimensions (W x D x H) |
900 x 900 x 1418 mm |
| Pallet weight |
100 kg |
| Print quality (black, draft quality) |
600 DPI |
| Quantity per pallet |
1 pc(s) |
| Standard media sizes |
A4, B4, B5, A5, A3 |
| Typefaces |
80 scalable TrueType fonts |
| Minimum system requirements for Macintosh |
Mac OS 10.2 and higher, 128 MB RAM, 25 MB available hard disk space, network or USB port |
| Print quality (black, best quality) |
1200 x 1200 DPI |
| Print quality (black, normal quality) |
600 DPI |
| Maximum dimensions (W x D x H) |
743 x 743 x 1183 mm |
| Print margin bottom (A4) |
2 mm |
| Print margin left (A4) |
2 mm |
| Print margin right (A4) |
2 mm |
| Print margin top (A4) |
2 mm |
| Driver updates |
The latest software and drivers are available for the HP LaserJet M5035 MFP from the HP Website at http:///support/ljm5035mfp |
| Duplex supported media size |
A3, A4 (L), A5, B4, B5 |
| Image scaling/enlargement range |
25 - 400% |
| Memory upgrade |
0.512 GB |
| Memory technology |
Memory Enhancement technology (MEt) |
| Control panel |
4 job control buttons, 13 button numeric keypad, touch screen graphical display, 3 status lights, 1 display contrast knob |
| Upgrade type |
Add additional input capacity with three 500 sheet trays with stand; DSS for additional digital sending capabilities |
| Auto document feeder: supported media types and capacity |
Sheets: 50 |
| Media weight (tray 2) |
60 to 120 g/m² |
| Media weight (tray 3) |
60 to 120 g/m² |
| Media size (tray 2) |
A4, B4, B5, LTR, LGL, EXE, A5, 215.9 x 330.2 mm |
| Media size (tray 3) |
A4, B4, B5, LTR, LGL, EXE, A5, A3, LGR, 215.9 x 330.2 mm |
| Maximum scan area |
27.9 cm (11") |
| Package dimensions (W x D x H) |
899.9 x 899.9 x 1418.1 mm (35.4 x 35.4 x 55.8") |
| Weight |
192 lb |
| Standard input capacity for envelopes |
10 sheets |
| Acoustic power emissions (active, print, copy or scan) |
71 dB |
| Acoustic power emissions (ready) |
Inaudible |
| Acoustic pressure emissions bystander (active, print, copy or scan) |
56 dB(A)
51 dB(A) |
| Acoustic pressure emissions bystander (ready) |
Inaudible |
| Auto fax reduction supported |
Y |
| Copier scaling (Auto Document Feeder) |
25 to 400% |
| Dimension note (imperial) |
base configuration |
| Dimension note (metric) |
base configuration |
| Duplex binding |
N |
| Fax memory (letter) |
Dependent on available hard disk space pages |
| Fax phone TAM interface supported |
N |
| Fax resolution (photo) |
200 x 200 dpi |
| Fax telephone mode supported |
Y |
| Feed speed (black & white, letter) |
Up to 35 ppm |
| Feed speed (colour, letter) |
Up to 23 ppm |
| First page out (black&white, A4, ready) |
8 s |
| First page out (black&white, letter, ready) |
8 s |
| First page out (black&white, letter, sleep) |
18 s |
| Junk barrier supported |
Y |
| Maximum input capacity (tray 1) |
100 sheets |
| Maximum input capacity (tray 2) |
Sheets: 250 |
| Maximum input capacity (tray 3) |
Sheets: 250 |
| Maximum printable area |
307.9 x 465.9 mm |
| Maximum scan area (Auto Document Feeder) |
11 x 17 |
| Media sizes supported (imperial) |
Executive, letter, legal, ledger |
| Memory per slot (maximum) |
512 |
| Memory per slot (standard) |
256 MB (internal fixed), 0 MB (installed in slot) |
| Minimum scan area (Auto Document Feeder) |
137.2 x 431.8 mm (5.4 x 17") |
| Minimum scan area |
279.4 x 431.8 mm (11 x 17") |
| Package weight |
220.46 lb |
| Paper sizes supported (Auto Document Feeder) |
Letter, legal, ledger, A4, A5, A3 |
| Print speed (grayscale, normal quality, A4 transparency) |
Up to 35 ppm |
| Remote retrieval capability |
Y |
| SureSupply connection type |
Direct and Network |
| SureSupply supported |
Y |
| Typical electricity consumption (TEC) number |
5.975 kWh/Week |
| Wireless option type |
Optional, enabled with purchase of a hardware accessory |
| Print speed (black, best quality, tabloid) |
Up to 18.5 ppm |
| Product dimensions (with optional paper finisher, metric) |
743 x 743 x 1183 mm (XS-bundle with optional input feeder and optional staple/stacker, X-bundle without staple/stacker is 997 mm high) |
| Recommended media weight (duplex, imperial) |
16 to 32 lb |
| Standard media sizes (duplex, imperial) |
Executive, letter, legal, ledger |
| Standard media sizes (duplex, metric) |
A3, A4 (L), A5, B4, B5 |
| UNSPSC-code |
43212110 |
| Digital sender features |
Send-to-network folder, LDAP & SMTP authentication, LDAP addressing |
| Security management description |
Private print, HP Secure Storage Erase, network authentication (LDAP SMTP), HP Jetdirect (802.1x) for wired networks, SNMPv3 and HTTPS, and Secure IPP (IPP-S) and IPsec |
| Pallet dimensions (W x D x H) (imperial) |
899.2 x 899.2 x 1417.3 mm (35.4 x 35.4 x 55.8") |
| Pallet weight (imperial) |
100 kg (220.5 lbs) |
| Weight (imperial) |
192 lb |
| Maximum scan area (ADF) (imperial) |
279.4 x 431.8 mm (11 x 17") |
| Package weight (imperial) |
100 kg (220.5 lbs) |
| Standard output capacity for transparencies |
200 sheets |
| Printer management |
HP Web Jetadmin; HP Easy Printer Care Software (neither is shipped in box) |
| Downloadable software |
Printing system, PCL 6 driver only, PCL 5 driver only, PS driver only, WJA applet, UPD PCL 5, UPD PS, HP Easy Printer Care Software, PC fax driver |
| Size (imperial) |
90 cm (35.4") |
| Electromagnetic compatibility |
CISPR 22:1993/EN 55022:1994 Class A, EN 61000-3-2:2000, EN 61000-3-3:1995, EN 55024:1998, FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, and carries the CE |
| Copier smart software features |
Up to A3 capable copying on the glass and through the automatic document feeder, 50 page ADF, duplexing (optional), reduce/enlarge, contrast adjustments, mixed originals support, stapling on xs bundle |
| Printer smart software features |
Up to A3 capable printing, full HP LaserJet printing functionality, HP ProRes 1200 at full engine speed, duplexing available, Instant-on Technology, HP Smart printing technology |
| Maximum scan area (imperial) |
27.9 cm (11") |
| Performance |
| Printing |
Mono printing |
| Copying |
Mono copying |
| Scanning |
Colour scanning |
| Faxing |
Colour faxing |
| Maximum duty cycle |
200000 pages per month |
| Digital sender |
N |
| Duplex functions |
print |
| Number of print cartridges |
1 |
| All-In-One-multitasking |
Y |
| Printer management |
HP Web Jetadmin; HP Easy Printer Care Software (neither is shipped in box) |
| Built-in processor |
Y |
| Processor clock speed |
460 MHz |
| Source data-sheet |
. |
| Processor frequency |
460 MHz |
| Market positioning |
Business |
| Internal memory |
256 MB |
| Internal storage capacity |
40 GB |
| Processor model |
MIPS |
| Processor family |
MIPS |
| Minimum system requirements |
133 MHz processor or higher, 64 MB RAM, 40 MB available hard disk space, USB or network port connection |
| Design |
| Electromagnetic compatibility |
CISPR 22:1993/EN 55022:1994 Class A, EN 61000-3-2:2000, EN 61000-3-3:1995, EN 55024:1998, FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, and carries the CE |
| Market positioning |
Business |
| Features |
| Printing |
Mono printing |
| Copying |
Mono copying |
| Scanning |
Colour scanning |
| Faxing |
Colour faxing |
| Maximum duty cycle |
200000 pages per month |
| Energy Star certified |
Y |
| Market positioning |
Business |
| Digital sender |
N |
| Duplex functions |
Print |
| Number of print cartridges |
1 |
| All-In-One-multitasking |
Y |
| Printer management |
HP Web Jetadmin; HP Easy Printer Care Software (neither is shipped in box) |
| Electromagnetic compatibility |
CISPR 22:1993/EN 55022:1994 Class A, EN 61000-3-2:2000, EN 61000-3-3:1995, EN 55024:1998, FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 4/GB9254-1998, GB17625.1-2003, EMC Directive 89/336/EEC and the Low Voltage Directive 73/23/EEC, and carries the CE |
| Page description languages |
PCL 5,PCL 6,PDF 1.4 |
| HP segment |
Enterprise |
| Processor |
| Built-in processor |
MIPS embedded in HP Custom ASIC |
| Processor frequency |
460 MHz |
| Logistics data |
| Pallet weight |
100 kg |
| Quantity per pallet |
1 pc(s) |
| Pallet gross weight |
100 kg |
| Products per pallet |
1 pc(s) |
| Input & output capacity |
| Standard input capacity |
1100 sheets |
| Standard output capacity |
250 sheets |
| Maximum input capacity |
2100 sheets |
| Maximum output capacity |
250 sheets |
| Maximum input capacity for envelopes |
Up to 10 envelopes |
| Standard output capacity for envelopes |
25 sheets |
| Total input capacity |
1100 sheets |
| Total output capacity |
250 sheets |
| Technical details |
| Sustainability certificates |
ENERGY STAR |
| Sustainability |
| Sustainability certificates |
ENERGY STAR |
