| Weight & dimensions |
| Width (with stand) |
540 mm |
| Depth (with stand) |
241 mm |
| Height (with stand) |
373 mm |
| Weight (with stand) |
5.4 kg |
| Power |
| Energy efficiency class (SDR) |
E |
| Energy efficiency class (HDR) |
Not available |
| Energy consumption (SDR) per 1000 hours |
17 kWh |
| Power consumption (typical) |
17 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (off) |
0.3 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power supply type |
Internal |
| Energy efficiency scale |
A to G |
| Display |
| Display diagonal |
60.5 cm (23.8") |
| Display resolution |
1920 x 1080 pixels |
| Native aspect ratio |
16:9 |
| Display technology |
LED |
| Touchscreen |
Yes |
| HD type |
Full HD |
| Panel type |
IPS |
| Response time |
4 ms |
| Screen shape |
Flat |
| Contrast ratio (typical) |
1000:1 |
| Maximum refresh rate |
83 Hz |
| Display number of colours |
16.7 million colours |
| LED backlight |
Yes |
| Touchscreen type |
Multi-user |
| Touchscreen technology |
Projected capacitive system |
| Touch technology |
Multi-touch |
| Number of simultaneous touchpoints |
10 |
| Display brightness (typical) |
300 cd/m² |
| Display brightness |
300 cd/m² |
| Response time measurement type |
GTG (Gray to Gray) |
| Anti-glare screen |
Yes |
| Supported graphics resolutions |
640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080) |
| Contrast ratio (dynamic) |
5000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.2745 x 0.2745 mm |
| Horizontal scan range |
30 - 83 kHz |
| Viewable size, horizontal |
52.7 cm |
| Viewable size, vertical |
29.6 cm |
| Display diagonal (metric) |
60.5 cm |
| Surface hardness |
3H |
| Colour depth |
8 bit |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Ports & interfaces |
| Built-in USB hub |
Yes |
| HDMI |
Yes |
| Headphone out |
Yes |
| USB hub version |
3.2 Gen 1 (3.1 Gen 1) |
| Number of upstream ports |
1 |
| Number of downstream ports |
2 |
| USB Type-A downstream ports quantity |
2 |
| USB Touch port |
Yes |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| HDCP |
Yes |
| Ergonomics |
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Height adjustment |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Wall mountable |
Yes |
| Cable management |
Yes |
| Cable lock slot type |
Kensington |
| Adjustable height (max) |
11.1 cm |
| Tilt adjustment |
Yes |
| Tilt angle range |
-5 - 90° |
| On Screen Display (OSD) |
Yes |
| On Screen Display (OSD) languages |
German, English, Spanish, French, Italian, Japanese, Dutch, Polish, Portuguese, Russian |
| Number of OSD languages |
10 |
| Plug and Play |
Yes |
| Other features |
| Compatible operating systems |
All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section. |
| Positional accuracy |
2 mm |
| Placement supported |
Horizontal/Vertical |
| Packaging content |
Screwdriver |
| Active display area (W x H) |
527.04 x 296.46 mm |
| USB ports quantity |
2 |
| Weight |
5.4 kg |
| Height |
373 mm |
| Width |
540 mm |
| Depth |
241 mm |
| Compliance certificates |
CE, EAC, REACH, RoHS, UKCA, WEEE |
| Mean time between failures (MTBF) |
50000 h |
| Certification |
CE, TÜV-Bauart, VCCI-B, EAC, ErP, WEEE, REACH, CB |
| User controls |
luminance (contrast, brightness, i-Style Color, adv. contrast, eco), Image settings (aspect ratio), Color settings (gamma, 6- axis, color temp), OSD (OSD horizontal position, OSD vertical position, OSD time, language), Extra (reset, DDC/CI, signal selec |
| Touch method |
finger, glove (latex), capacitive stylus |
| Control panel |
Power, menu, +, -, Exit |
| Optical drive player software |
Y |
| Design |
| Market positioning |
Business |
| Product colour |
Black |
| Front bezel colour |
Black |
| Performance |
| NVIDIA G-SYNC |
No |
| AMD FreeSync |
No |
| Flicker-free technology |
Yes |
| Low Blue Light technology |
Yes |
| Windows operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| OmniTapps Multitouch compatibility |
Yes |
| Multimedia |
| Built-in speaker(s) |
Yes |
| Built-in camera |
No |
| Number of speakers |
2 |
| RMS rated power |
4 W |
| Megapixel (approx.) |
2.1 MP |
| Packaging data |
| Package width |
615 mm |
| Package depth |
148 mm |
| Package height |
420 mm |
| Package weight |
7.1 kg |
| Logistics data |
| Harmonized System (HS) code |
85285210 |
| Packaging content |
| Cables included |
AC, USB, HDMI |
| Quick start guide |
Yes |
| Sustainability |
| Sustainability certificates |
EPEAT, ErP |
