| Weight & dimensions |
| Width |
102 mm |
| Depth |
53.5 mm |
| Height |
53 mm |
| Weight |
120 g |
| Packaging data |
| Quantity |
1 |
| Package type |
Box |
| Package width |
155 mm |
| Package depth |
95 mm |
| Package height |
60 mm |
| Package weight |
210 g |
| Design |
| Built-in microphone |
Yes |
| Interface |
USB |
| Product colour |
Black |
| Mounting type |
Clip/Stand |
| Built-in flash |
No |
| Housing material |
Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| Sensor type |
CMOS |
| Optical sensor size |
25.4 / 2.9 mm (1 / 2.9") |
| Image stabilizer |
No |
| Cable length |
1.5 m |
| Performance |
| Megapixel (approx.) |
2.07 MP |
| Maximum video resolution |
1920 x 1080 pixels |
| Camera HD type |
Full HD |
| Face tracking |
No |
| Maximum frame rate |
30 fps |
| Resolution at capture speed |
640x480@30fps, 1280x720@30fps, 1920x1080@30fps |
| Supported video modes |
720p, 1080p |
| Video formats supported |
H.264, M-JPEG, YUV |
| Maximum image resolution |
1920 x 1080 pixels |
| Auto focus |
Yes |
| Signal-to-Noise Ratio (SNR) |
50 dB |
| Power consumption (typical) |
5 W |
| Operating voltage |
5 V |
| Operating current |
0.5 A |
| Plug and Play |
Yes |
| Technical details |
| Warranty period |
2 year(s) |
| Packaging content |
| Quick installation guide |
Yes |
| Box contents |
1 x USB™ HD Webcam with 360° rotation (Model: JVCU100), 1 x Quick Installation Guide |
| Logistics data |
| Quantity per box |
1 pc(s) |
| Products per shipping (inner) case |
3 pc(s) |
| Shipping (inner) case length |
20.7 cm |
| Shipping (inner) case width |
10.3 cm |
| Shipping (inner) case height |
16.5 cm |
| Export Control Classification Number (ECCN) |
EAR99 |
| Shipping (inner) case gross weight |
740 g |
| Commodity Classification Automated Tracking System (CCATS) |
8525.50.0000 |
| Master (outer) case width |
230 mm |
| Master (outer) case length |
435 mm |
| Master (outer) case height |
190 mm |
| Master (outer) case gross weight |
3.04 kg |
| Master (outer) case GTIN (EAN/UPC) |
24712795085574 |
| Products per master (outer) case |
12 pc(s) |
| Country of origin |
Taiwan |
| Software |
| Windows operating systems supported |
Windows 10, Windows 8.1, Yes |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS |
| Linux operating systems supported |
Yes |
| Other operating systems supported |
ChromeOS |
| Operational conditions |
| Storage relative humidity (H-H) |
0 - 90% |
| Operating relative humidity (H-H) |
0 - 90% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| System requirements |
| Minimum system requirements |
Available USB™ Type-A port, Windows® 10, macOS® with UVC support, Chrome OS™ with UVC support, Operating systems compliant with standard UVC 1.0/1.1 & UAC support |
