Stock Status: 1x unit in stock
The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "Lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.
ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.
The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.
Specs
| Networking |
| Maximum data transfer rate |
10000 Mbit/s |
| Networking standards |
IEEE 802.1Q, IEEE 802.1Qbg, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3x |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000,10000 Mbit/s |
| Cabling technology |
10GBase-T |
| Security algorithms |
SNMP |
| Jumbo frames support |
Yes |
| Jumbo frames |
9728 |
| Quality of Service (QoS) support |
Yes |
| VLAN tagging |
Yes |
| System requirements |
| Linux operating systems supported |
Red Hat Enterprise Linux WS 6.0, Red Hat Enterprise Linux WS 7.0, openSUSE 11.3, openSUSE 11.4, openSUSE 12.1, openSUSE 12.2 |
| Other operating systems supported |
VMware vSphere ESXi |
| Server operating systems supported |
Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2016 |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
PCI Express |
| Interface |
Ethernet |
| Ethernet LAN (RJ-45) ports |
4 |
| Other features |
| Flow control support |
Yes |
| Number of VLANs |
4096 |
| PCI-SIG* SR-IOV Capable |
Yes |
| Receive Side Scaling (RSS) |
Yes |
| Design |
| Internal |
Yes |
| Product colour |
Green |
| Chipset |
Intel® C624 |
| Certification |
UL recognized to UL60950-1 2nd Edition
FCC Rules, Part 15, Class A
Australian EMC Framework (RCM)
Japan VCCI, Class A
Industry Canada, ICES-003, Class A
EU (CE Mark)
Korea KC-RRA, Class A |
| Compatible products |
SR630
SR650
SR850
SR860
SR950 |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Technical details |
| Compliance certificates |
RoHS |
Features
Lenovo 7ZT7A00549. Internal. Connectivity technology: Wired, Host interface: PCI Express, Interface: Ethernet. Maximum data transfer rate: 10000 Mbit/s. Product colour: Green
Product Description
The Intel Ethernet Connection X722 is a network controller embedded into the Intel C624 "Lewisburg" PCH chipset of Lenovo ThinkSystem servers. The controller connects to available 10 GbE and 1 Gigabit Ethernet LAN-on-motherboard (LOM) adapter cards and onboard connectors to provide a comprehensive 1 GbE / 10 GbE networking solution for ThinkSystem customers.
ThinkSystem servers support either 10 Gb Ethernet copper or optical connections, or Gigabit Ethernet connections depending on the server model.
The following figure shows the ThinkSystem 10Gb 4-port SFP+ LOM adapter which provides four SFP+ cages for optical or direct-attach copper (DAC) connectivity.
