Stock Status: 1x unit in stock
The halogen-free sheath material of the LSZH cable makes the product suitable for use in public spaces with its low smoke emission and elimination of toxic halogen emissions. Ideal for safety-critical installations, this cable is perfectly suited for public environments such as schools, transport hubs, and government buildings, anywhere safety compliance and performance are essential.
The cable features a double shielded construction with 30AWG bare copper for premium performance featuring gold connectors and gold flashed contacts to maintain signal integrity and reliability.
Supporting 18Gbps bandwidth the Lindy LSZH HDMI® Cable can support UHD resolutions up to 3840x2160@60Hz 4:4:4 8bit. Whilst also transmitting up to 32 Channel audio including Dolby® True HD & DTS-HD Master Audio.
The Lindy LSZH HDMI® Cable is available in lengths from 0.5m to 10m.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Specs
| Features |
| Cable length |
5 m |
| Connector 1 |
HDMI Type A (Standard) |
| Connector 2 |
HDMI Type A (Standard) |
| Connector 1 gender |
Male |
| Connector 2 gender |
Male |
| HDMI cable type |
High Speed HDMI cable |
| Product colour |
Black |
| Connector contacts plating |
Gold |
| Connector 1 form factor |
Straight |
| Connector 2 form factor |
Straight |
| 3D |
Yes |
| Supported graphics resolutions |
3840 x 2160 |
| Supported video modes |
2160p |
| Dolby technologies |
DTS-HD Master Audio, Dolby TrueHD |
| Data transfer rate |
18 Gbit/s |
| Supported digital audio channels (uncompressed) |
32 |
| Maximum refresh rate |
60 Hz |
| AWG wire size |
30 |
| Cable material |
Copper |
| Cable type |
Round cable |
| Cable jacket material |
Low smoke zero halogen (LSZH), Polyvinyl chloride (PVC) |
| Magnetically shielded |
Yes |
| Shield material |
Aluminium |
| Bending radius (min) |
6 cm |
| Plug and Play |
Yes |
| Colour sampling |
4:4:4 |
| Nominal attenuation |
300kHz~825MHz<5dB
825MHz~2.475GHz<5dB
2.475GHz~4.125GHz<12dB
4.125GHz~5.1GHz<20dB |
| Weight & dimensions |
| Cable diameter |
5.5 mm |
| Operational conditions |
| Operating temperature (T-T) |
-10 - 80 °C |
| Storage temperature (T-T) |
-20 - 85 °C |
| Packaging data |
| Quantity per pack |
1 pc(s) |
| Package type |
Polybag |
| Certification |
| Compliance certificates |
REACH, RoHS |
| Sustainability |
| Doesn't contain |
Halogen |
Features
Lindy 36505. Cable length: 5 m, Connector 1: HDMI Type A (Standard), Connector 1 gender: Male, Connector 2: HDMI Type A (Standard), Connector 2 gender: Male, Connector contacts plating: Gold, 3D, Data transfer rate: 18 Gbit/s, Product colour: Black
Product Description
The halogen-free sheath material of the LSZH cable makes the product suitable for use in public spaces with its low smoke emission and elimination of toxic halogen emissions. Ideal for safety-critical installations, this cable is perfectly suited for public environments such as schools, transport hubs, and government buildings, anywhere safety compliance and performance are essential.
The cable features a double shielded construction with 30AWG bare copper for premium performance featuring gold connectors and gold flashed contacts to maintain signal integrity and reliability.
Supporting 18Gbps bandwidth the Lindy LSZH HDMI® Cable can support UHD resolutions up to 3840x2160@60Hz 4:4:4 8bit. Whilst also transmitting up to 32 Channel audio including Dolby® True HD & DTS-HD Master Audio.
The Lindy LSZH HDMI® Cable is available in lengths from 0.5m to 10m.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
