Stock Status: 1x unit in stock
Reliable rack power distribution designed to increase manageability and efficiency in the data center The output and input connections are (12)C13 Real-time remote monitoring of connected loads User-defined alarms warn IT and data center managers of potential circuit overloads to prevent accidental power loss to critical equipment.
Specs
| Weight & dimensions |
| Dimensions (WxDxH) |
447 x 57.2 x 44.5 mm |
| Weight |
2.05 kg |
| Operational conditions |
| Operating temperature (T-T) |
0 - 45 °C |
| Storage temperature (T-T) |
-25 - 65 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Power |
| Load capacity |
3680 VA |
| Maximum input current per phase |
16 A |
| Maximum power |
3680 W |
| Ports & interfaces |
| AC outlets quantity |
12 AC outlet(s) |
| AC outlet types |
C13 coupler |
| Power plug |
C20 coupler |
| Input connection type |
IEC-320 C20 |
| Output connections |
(12) IEC 320 C13 |
| Design |
| PDU types |
Basic |
| Rack capacity |
0U/1U |
| Type |
Single-phase |
| Mounting |
Horizontal/Vertical |
| Product colour |
Black |
| Features |
| Cable length |
2.5 m |
| Certification |
cUL Listed,CE,CSA,GOST,Queensland Australia,UL 60950,UL Listed,VDE |
| Packaging data |
| Package dimensions (WxDxH) |
464 x 229 x 70 mm |
| Package weight |
3.64 kg |
Features
APC Basic Rack PDU. PDU types: Basic, Rack capacity: 0U/1U, Type: Single-phase. AC outlets quantity: 12 AC outlet(s), AC outlet types: C13 coupler, Power plug: C20 coupler. Cable length: 2.5 m, Certification: cUL Listed,CE,CSA,GOST,Queensland Australia,UL 60950,UL Listed,VDE. Load capacity: 3680 VA, Maximum input current per phase: 16 A, Maximum power: 3680 W. Dimensions (WxDxH): 447 x 57.2 x 44.5 mm, Weight: 2.05 kg
Product Description
Reliable rack power distribution designed to increase manageability and efficiency in the data center The output and input connections are (12)C13 Real-time remote monitoring of connected loads User-defined alarms warn IT and data center managers of potential circuit overloads to prevent accidental power loss to critical equipment.
