| Ports & interfaces |
| Number of computers controlled |
1 |
| Keyboard port type |
USB |
| Mouse port type |
USB |
| Video port type |
VGA |
| Console USB ports quantity |
1 |
| USB connector type |
Mini-USB B |
| Audio connections |
No |
| Weight & dimensions |
| Width |
74 mm |
| Depth |
115 mm |
| Height |
15 mm |
| Weight |
170 g |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
0 - 80% |
| Power |
| Power source |
USB |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Window |
| Linux operating systems supported |
Yes |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura |
| Server operating systems supported |
Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Display |
| Built-in display |
No |
| On Screen Display (OSD) |
No |
| Packaging content |
| Cables included |
USB |
| Software included |
Yes |
| Other features |
| Compatible operating systems |
Windows 8 (32/64bit), 7 (32/64), Vista(32/64), XP(32/64)
Windows Server 2012, 2008 R2
Mac OS 10.x (Tested up to 10.9)
Linux 2.6.x - 3.5.x (32/64bit) |
| Design |
| Rack mounting |
No |
| Product colour |
Black |
| Housing material |
Plastic |
| Cable length |
0.416 m |
| LED indicators |
Yes |
| Mean time between failures (MTBF) |
909000 h |
| Certification |
CE, FCC, TAA, UL |
| Performance |
| HD type |
Full HD |
| Maximum resolution |
1920 x 1200 pixels |
| Video bandwidth |
60 Hz |
| Plug and Play |
Yes |
| Daisy chain |
No |
| Number of users |
1 user(s) |
| Logistics data |
| Harmonized System (HS) code |
85176200 |
| Master (outer) case width |
320 mm |
| Master (outer) case length |
520 mm |
| Master (outer) case height |
525 mm |
| Products per master (outer) case |
30 pc(s) |
| Packaging data |
| Package width |
166 mm |
| Package depth |
303 mm |
| Package height |
46 mm |
| Package weight |
363 g |
| Sustainability |
| Compliance certificates |
RoHS |
