Stock Status: 1x unit in stock
External SSD/HDD Docking Station | USB 3.2 Gen 2 (10 Gbps) to SATAUnleash the power of USB 3.1 Gen 2 (10 Gbps) with this single-drive docking station. It supports both 2.5” and 3.5” form factors for solid-state and hard drives, with a high drive capacity of 6TB.Harness the speed of USB 3.1 Gen 2USB 3.1 Gen 2 gives you greater bandwidth and speed with file transfer rates of up to 10 Gbps - twice the speed of USB 3.0 (USB 3.1 Gen 1) technology. It lets you leverage the high performance of the latest SSDs and hard drives, while alleviating bottlenecks in your data transfers.Top-loading design for easy drive accessIt’s never been easier to dock and swap drives from your desktop computer or laptop. Simply insert your drives into the top loading slot, with no tools or trays required. The HDD ejection button allows fast and simple drive removal.Convenient compatibilityThe docking station comes with a USB Type-A to B cable, providing backward compatibility with your existing USB 3.0, 2.0 and 1.x devices. It also supports UASP for enhanced performance.The SDOCKU313 is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage
Specs
| Hard drive |
| Storage media type |
HDD, SSD |
| Storage drive interface |
Serial ATA III |
| Storage drive sizes supported |
2.5,3.5" |
| Number of storage drives supported |
1 |
| Maximum storage capacity |
6 TB |
| Technical details |
| Sustainability certificates |
RoHS |
| Weight & dimensions |
| Width |
92.7 mm |
| Depth |
145 mm |
| Height |
64 mm |
| Weight |
392 g |
| Power |
| AC input voltage |
110 - 240 V |
| Input current |
0.6 A |
| Output voltage |
12 V |
| Output current |
2 A |
| Power plug type |
Type M |
| Packaging data |
| Package width |
163 mm |
| Package depth |
91 mm |
| Package height |
171 mm |
| Package weight |
758 g |
| Packaging content |
| AC adapter included |
Y |
| Cables included |
USB |
| Included power plug types |
AU, EU, NA, UK |
| Quick installation guide |
Y |
| Cooling |
| Built-in fan |
N |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
-20 - 50 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Ports & interfaces |
| Host interface |
USB 3.2 Gen 2 (3.1 Gen 2) Type micro-B |
| USB 3.2 Gen 2 (3.1 Gen 2) ports quantity |
1 |
| DC-in jack |
Y |
| Logistics data |
| Harmonized System (HS) code |
84733080 |
| Master (outer) case width |
385 mm |
| Master (outer) case length |
475 mm |
| Master (outer) case height |
185 mm |
| Products per master (outer) case |
10 pc(s) |
| Features |
| Maximum data transfer rate |
10 Gbit/s |
| Product colour |
Black |
| Material |
Plastic |
| LED indicators |
Activity, Power |
| UASP support |
Y |
| Chipset |
ASMedia - ASM1351 |
| Certification |
CE, FCC, REACH |
Features
StarTech.com Single Bay USB 3.1 to SATA Hard Drive Docking Station, USB 3.1 (10 Gbps) Hard Drive Dock, External 2.5/3.5" SATA III HDD/SSD Docking Station, Top-Loading Hard Drive Bay. Storage media type: HDD, SSD, Storage drive interface: Serial ATA III, Storage drive sizes supported: 2.5,3.5". Host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type micro-B. Maximum data transfer rate: 10 Gbit/s, Product colour: Black, Material: Plastic. AC input voltage: 110 - 240 V, Input current: 0.6 A, Output voltage: 12 V. Width: 92.7 mm, Depth: 145 mm, Height: 64 mm
Product Description
External SSD/HDD Docking Station | USB 3.2 Gen 2 (10 Gbps) to SATAUnleash the power of USB 3.1 Gen 2 (10 Gbps) with this single-drive docking station. It supports both 2.5” and 3.5” form factors for solid-state and hard drives, with a high drive capacity of 6TB.Harness the speed of USB 3.1 Gen 2USB 3.1 Gen 2 gives you greater bandwidth and speed with file transfer rates of up to 10 Gbps - twice the speed of USB 3.0 (USB 3.1 Gen 1) technology. It lets you leverage the high performance of the latest SSDs and hard drives, while alleviating bottlenecks in your data transfers.Top-loading design for easy drive accessIt’s never been easier to dock and swap drives from your desktop computer or laptop. Simply insert your drives into the top loading slot, with no tools or trays required. The HDD ejection button allows fast and simple drive removal.Convenient compatibilityThe docking station comes with a USB Type-A to B cable, providing backward compatibility with your existing USB 3.0, 2.0 and 1.x devices. It also supports UASP for enhanced performance.The SDOCKU313 is backed by a StarTech.com 2-year warranty and free lifetime technical support.The StarTech.com Advantage
