| Weight & dimensions |
| Width |
76 mm |
| Depth |
227 mm |
| Height |
24 mm |
| Weight |
277 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| HDMI ports quantity |
1 |
| Headphone outputs |
1 |
| DisplayPorts quantity |
1 |
| Headphone connectivity |
3.5 mm |
| USB connector type |
USB Type-A |
| Power |
| AC input voltage |
100-240 V |
| Input current |
1.5 A |
| Output voltage |
5 V |
| Output current |
6.5 A |
| Power consumption (typical) |
32.5 W |
| Compatible power plug types |
AU,EU,UK,US |
| Packaging content |
| Cables included |
AC, USB |
| AC adapter included |
Y |
| Manual |
Y |
| Drivers included |
Y |
| Other features |
| Cable length |
0.6 m |
| Chipset |
DisplayLink - DL-5900, VLI - VL812 |
| USB data transfer rates |
5000 Mbit/s |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-10 - 80 °C |
| Operating relative humidity (H-H) |
0 - 90% |
| Networking |
| Ethernet LAN |
Y |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wake-on-LAN ready |
Y |
| Networking standards |
IEEE 802.3,IEEE 802.3ab,IEEE 802.3u |
| Auto MDI/MDI-X |
Y |
| Full duplex |
Y |
| Performance |
| Product colour |
Black |
| Card reader integrated |
N |
| Data transfer rate |
5 Gbit/s |
| Maximum digital resolution |
3840 x 2160 pixels |
| Cable lock slot |
Y |
| LED indicators |
Activity, Link |
| Charging function |
Y |
| UASP support |
Y |
| Housing material |
Plastic, Steel |
| Brand compatibility |
Any brand |
| RoHS compliance |
Y |
| Certification |
CE, FCC, DisplayLink |
| Technical details |
| Sustainability certificates |
RoHS |
| Software |
| Windows operating systems supported |
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 Pro,Windows 10 Pro x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Win |
| Mac compatibility |
Y |
| Mac operating systems supported |
Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.14 Mojave |
| Other operating systems supported |
Chrome |
| Packaging data |
| Package width |
251 mm |
| Package depth |
198 mm |
| Package height |
71 mm |
| Package weight |
1.1 kg |
| Logistics data |
| Master (outer) case width |
37 cm |
| Master (outer) case length |
41.5 cm |
| Master (outer) case height |
27.5 cm |
| Quantity per shipping (inner) case |
150 pc(s) |
| Products per shipping (inner) case |
150 pc(s) |
| Sustainability |
| Sustainability certificates |
RoHS |
