| System requirements |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows |
| Linux operating systems supported |
Y |
| Server operating systems supported |
Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Ports & interfaces |
| Host interface |
PCI/PCI-X |
| Output interface |
Serial |
| Expansion card form factor |
Full-height / Low-profile |
| Serial ports quantity |
2 |
| Serial interface type |
RS-232 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-20 - 85 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
| Width |
21.6 mm |
| Depth |
134 mm |
| Height |
120 mm |
| Weight |
141 g |
| Design |
| Internal |
Y |
| Product colour |
Black |
| Logistics data |
| Harmonized System (HS) code |
84733020 |
| Products per master (outer) case |
40 pc(s) |
| Master (outer) case width |
360 mm |
| Master (outer) case length |
385 mm |
| Master (outer) case height |
340 mm |
| Packaging data |
| Mounting brackets included |
Y |
| User guide |
Y |
| Package width |
142 mm |
| Package depth |
170 mm |
| Package height |
30 mm |
| Package weight |
190 g |
| Features |
| Chipset |
Asix - MCS9865 |
| Data transfer rate (max) |
0.0015 Gbit/s |
| Baud rate |
115.2 Kbit/s |
| FIFO (First In, First Out) |
256 B |
| Data bits |
5, 6, 7, 8, 9 |
| Stop bits |
1, 1.5, 2 |
| Parity bit |
Even, Mark, N, Odd, Space |
| Flow Control type |
N, RTS/CTS, XON/XOFF |
| Technical details |
| Sustainability certificates |
CE, RoHS |
