| Weight & dimensions |
| Width |
128 mm |
| Depth |
55 mm |
| Height |
19 mm |
| Weight |
105 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 2.0 ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| HDMI ports quantity |
0 |
| Microphone in |
No |
| Headphone outputs |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery up to |
100 W |
| Serial ports quantity |
1 |
| Power |
| Power consumption (max) |
15 W |
| Packaging content |
| Quick start guide |
Yes |
| Interface adapters included |
USB Type-A male - USB Type-C female |
| Other features |
| Chipset |
VIA - VL817-Q7, VIA - VL103-Q4, ASIX - AX88179A, FTDI - FT232RL |
| Operational conditions |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10,100,1000,2000 Mbit/s |
| Wake-on-LAN ready |
Yes |
| Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Jumbo frames support |
Yes |
| Jumbo frames |
9000 |
| Flow control support |
Yes |
| Auto MDI/MDI-X |
Yes |
| Full duplex |
Yes |
| VLAN tagging |
Yes |
| Performance |
| Product colour |
Grey |
| Card reader integrated |
No |
| Colour name |
Space Gray |
| Data transfer rate |
5 Gbit/s |
| LED indicators |
Yes |
| UASP support |
Yes |
| Technical details |
| Compliance certificates |
CE, RoHS |
| Software |
| Windows operating systems supported |
Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS |
| Linux operating systems supported |
Yes |
| Server operating systems supported |
Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022 |
| Other operating systems supported |
Windows XP Embedded |
| Packaging data |
| Package width |
142 mm |
| Package depth |
170 mm |
| Package height |
30 mm |
| Package weight |
110 g |
| Logistics data |
| Products per master (outer) case |
80 pc(s) |
| Master (outer) case width |
605 mm |
| Master (outer) case length |
325 mm |
| Master (outer) case height |
385 mm |
| Sustainability |
| Sustainability compliance |
Yes |
