| Networking |
| Maximum data transfer rate |
2000 Mbit/s |
| Networking standards |
IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x |
| Ethernet LAN |
Y |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000BaseT(X) |
| Auto MDIX IEEE |
Y |
| Full duplex |
Y |
| Jumbo frames support |
Y |
| VLAN tagging |
Y |
| Maximum operating distance |
100 m |
| Jumbo frames |
9000 |
| System requirements |
| Windows operating systems supported |
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 7,Windows 7 Enterprise,Windows 7 Ente |
| Mac operating systems supported |
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks |
| Linux operating systems supported |
Y |
| Other operating systems supported |
Chrome |
| Server operating systems supported |
Windows Server 2003,Windows Server 2008 R2,Windows Server 2012,Windows Server 2016,Windows Server 2019 |
| Weight & dimensions |
| Width |
24.9 mm |
| Depth |
66 mm |
| Height |
17 mm |
| Weight |
36 g |
| Ports & interfaces |
| Connectivity technology |
Wired |
| Host interface |
USB |
| Interface |
Ethernet |
| Ethernet LAN (RJ-45) ports |
1 |
| USB version |
3.2 Gen 1 (3.1 Gen 1) |
| Operational conditions |
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-55 - 125 °C |
| Operating relative humidity (H-H) |
20 - 90% |
| Other features |
| Chipset |
Realtek RTL8153 |
| Housing material |
Aluminium |
| Quick start guide |
Y |
| Flow control support |
Y |
| Jumbo frames |
9000 |
| Design |
| Internal |
N |
| Product colour |
Silver |
| LED indicators |
Activity, Link, Power |
| Chipset |
Realtek RTL8153 |
| Logistics data |
| Master (outer) case width |
37 cm |
| Master (outer) case length |
42 cm |
| Master (outer) case height |
35 cm |
| Products per master (outer) case |
120 pc(s) |
| Packaging data |
| Package width |
112 mm |
| Package depth |
204 mm |
| Package height |
21 mm |
| Package weight |
100 g |
