| Wireless LAN features |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) |
867 Mbit/s |
| WLAN data transfer rate (first band) |
300 Mbit/s |
| WLAN data transfer rate (second band) |
867 Mbit/s |
| Wi-Fi standards |
802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac) |
| Ports & interfaces |
| USB port |
N |
| Ethernet LAN (RJ-45) ports |
1 |
| DC-in jack |
Y |
| Memory card slot(s) |
N |
| Mobile networking |
| 3G |
N |
| 4G |
N |
| Mobile network generation |
4G |
| Networking |
| Networking standards |
IEEE 802.3af |
| Guest access |
Y |
| Ethernet LAN |
Y |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| Antenna |
| Antenna type |
Internal |
| Transmit power |
CE:≤20dBm(2.4GHz,EIRP), ≤23dBm(5GHz,EIRP), FCC:≤24dBm(2.4GHz), ≤22dBm(5GHz) |
| Management features |
| Reset button |
Y |
| Quality of Service (QoS) support |
Y |
| Web-based management |
Y |
| Security |
| Security algorithms |
64-bit WEP,128-bit WEP,152-bit WEP,SSID,WPA,WPA-PSK,WPA2,WPA2-PSK |
| Guest access |
Y |
| Power |
| Power source type |
AC |
| Output voltage |
12 V |
| Output current |
1.5 A |
| Power supply |
10.15 W |
| Weight & dimensions |
| Width |
180 mm |
| Depth |
180 mm |
| Height |
47.5 mm |
| System requirements |
| Windows operating systems supported |
Windows 10,Windows 7,Windows 8,Windows Vista,Windows XP |
| Linux operating systems supported |
Y |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Packaging content |
| AC adapter included |
Y |
| Quick start guide |
Y |
| Package type |
Box |
| Ethernet LAN features |
| Ethernet LAN |
Y |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| Design |
| Product type |
Portable router |
| Product colour |
White |
| Indication light |
Y |
| LED indicators |
Power, WLAN |
| On/off switch |
Y |
| Wall mountable |
Y |
| Performance |
| Memory card slot(s) |
N |
| WAN connection |
| Ethernet WAN |
Y |
| DSL WAN |
N |
| SIM card slot |
N |
| 3G/4G USB modem compatibility |
N |
| Packaging data |
| AC adapter included |
Y |
| Quick start guide |
Y |
| Package type |
Box |
| Manual |
Y |
| Quick installation guide |
Y |
| Number of products included |
1 pc(s) |
