| Wireless LAN features |
| Wi-Fi band |
Dual-band (2.4 GHz / 5 GHz) |
| Top Wi-Fi standard |
Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) |
867 Mbit/s |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (first band) |
867 Mbit/s |
| WLAN data transfer rate (second band) |
300 Mbit/s |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
4 |
| USB port |
No |
| Memory card slot(s) |
Yes |
| DC-in jack |
Yes |
| Mobile networking |
| Mobile network generation |
4G |
| Dual SIM support |
No |
| 3G standards |
HSPA, HSPA+, UMTS |
| 4G standard |
LTE |
| UMTS bands supported |
850,900,2100 MHz |
| 4G bands supported |
700,800,850,900,1800,2100,2300,2500,2600 MHz |
| SIM card type |
MicroSIM |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Gigabit Ethernet |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Dynamic DNS (DDNS) |
Yes |
| Number of guest networks (2.4 GHz) |
1 |
| Number of guest networks (5 GHz) |
1 |
| VPN support |
PPTP VPN, IPSec VPN , OpenVPN |
| Receiver sensitivity |
5 GHz: 11a 54M: -74 dBm
11ac HT20: -66 dBm
11ac HT40: -63 dBm
11ac HT80 : -59 dBm
11n HT20: -73 dBm
11n HT40: -70 dBm
2.4 GHz: 11g 54M: -74 dBm
11n HT20: -72 dBm
11n HT40: -69 dBm |
| Protocols |
| DHCP client |
Yes |
| DHCP server |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| Routing protocols |
IP |
| Supported network protocols |
IPv4, IPv6 |
| Antenna |
| Antenna design |
External |
| Antennas quantity |
2 |
| Detachable antenna(s) |
Yes |
| Management features |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Quality of Service (QoS) support |
No |
| Reset button |
Yes |
| WPS push button |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Security |
| Security algorithms |
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Firewall |
Yes |
| Firewall security |
Domain Filter, IP, MAC Address Binding |
| Guest access |
Yes |
| Stateful Packet Inspection (SPI) |
Yes |
| DoS attack prevention |
Yes |
| Parental control |
Yes |
| Filtering |
Yes |
| URL filtering |
Yes |
| DMZ support |
Yes |
| Power |
| Power source type |
AC, DC |
| AC input voltage |
110 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Output voltage |
12 V |
| Output current |
1.5 A |
| Weight & dimensions |
| Width |
229 mm |
| Depth |
160 mm |
| Height |
37 mm |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP, Yes |
| Linux operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage relative humidity (H-H) |
5 - 90% |
| Design |
| Product type |
Tabletop router |
| Product colour |
Black |
| LED indicators |
LAN, Power, WLAN |
| WAN connection |
| Ethernet WAN |
Yes |
| SIM card slot |
Yes |
| 3G/4G USB modem compatibility |
Yes |
| WAN connection type |
RJ-45 |
| Packaging data |
| Package width |
307 mm |
| Package depth |
223 mm |
| Package height |
70 mm |
| Package type |
Box |
| Number of products included |
1 pc(s) |
| Package weight |
810 g |
| Packaging content |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Quick installation guide |
Yes |
