| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity |
16 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Installed SFP+ modules quantity |
0 |
| SFP module slots quantity |
1 |
| Power connector |
DC-in jack |
| Networking |
| Networking standards |
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support |
No |
| Copper ethernet cabling technology |
10BASE-T, 100BASE-TX, 1000BASE-T |
| Port mirroring |
Yes |
| Full duplex |
Yes |
| Flow control support |
Yes |
| Link aggregation |
Yes |
| Rate limiting |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| VLAN support |
Yes |
| Virtual LAN features |
Port-based VLAN, Tagged VLAN |
| Number of VLANs |
64 |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 70 °C |
| Operating altitude |
0 - 3000 m |
| Non-operating altitude |
0 - 3000 m |
| Weight & dimensions |
| Width |
286 mm |
| Depth |
102 mm |
| Height |
27 mm |
| Weight |
880 g |
| Security |
| DHCP features |
DHCP client |
| IGMP snooping |
Yes |
| Password protection |
Yes |
| Queue scheduling algorithms |
Weighted Round Robin (WRR) |
| Data transmission |
| MAC address table |
4096 entries |
| Switching capacity |
32 Gbit/s |
| Store-and-forward |
Yes |
| Jumbo frames support |
Yes |
| Jumbo frames |
10000 |
| Packet buffer memory |
0.192 MB |
| Management features |
| Switch type |
Managed |
| Quality of Service (QoS) support |
Yes |
| Web-based management |
Yes |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
Yes |
| Power over Ethernet plus (PoE+) ports quantity |
15 |
| Total Power over Ethernet (PoE) budget |
231 W |
| Design |
| Rack mounting |
No |
| Product colour |
Black |
| Housing material |
Metal |
| LED indicators |
Yes |
| Wall mountable |
Yes |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
| Multicast features |
| Multicast support |
Yes |
| Number of multicast groups filtered |
128 |
| Certification |
| Compliance certificates |
CE |
| Certification |
FCC 15 B
CE/EN55032/24
VCCI
ACMA
CSA
KC
BSMI |
| Packaging content |
| Cables included |
AC |
| User guide |
Yes |
| Sustainability |
| Sustainability compliance |
Yes |
