| Processor |
| Processor family |
Intel Core Ultra 9 |
| Processor manufacturer |
Intel |
| Processor model |
285K |
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor cores |
24 |
| Processor threads |
24 |
| Processor boost frequency |
5.7 GHz |
| Performance cores |
8 |
| Efficient cores |
16 |
| Performance-core Max Turbo Frequency |
5.5 GHz |
| Efficient-core Max Turbo Frequency |
4.6 GHz |
| Performance-core base frequency |
3.7 GHz |
| Efficient-core base frequency |
3.2 GHz |
| Processor cache |
36 MB |
| Processor cache type |
Smart Cache |
| Number of processors installed |
1 |
| Processor base power |
125 W |
| Maximum turbo power |
250 W |
| Memory |
| Internal memory |
32 GB |
| Maximum internal memory |
64 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory layout (slots x size) |
2 x 16 GB |
| Memory slots |
2x DIMM |
| Memory channels |
Dual-channel |
| Memory data transfer rate |
5200 MT/s |
| Ports & interfaces |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
5 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
2 |
| Thunderbolt 3 ports quantity |
0 |
| HDMI ports quantity |
0 |
| USB4 Gen 2x2 ports quantity |
1 |
| PowerShare |
Yes |
| Number of USB ports with PowerShare support |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| Line-out |
Yes |
| Line-in |
Yes |
| Combo headphone/mic port |
Yes |
| S/PDIF out port |
Yes |
| Total number of SATA connectors |
3 |
| Power |
| Power supply |
1000 W |
| Power supply input voltage |
90 - 264 V |
| Power supply input frequency |
47 - 63 Hz |
| 80 PLUS certification |
80 PLUS Platinum |
| Operational conditions |
| Operating temperature (T-T) |
10 - 35 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating altitude |
-15.2 - 3048 m |
| Non-operating altitude |
-15.2 - 10668 m |
| Operating vibration |
0.26 G |
| Non-operating vibration |
1.37 G |
| Operating shock |
40 G |
| Non-operating shock |
105 G |
| Weight & dimensions |
| Width |
197 mm |
| Depth |
458.4 mm |
| Height |
418 mm |
| Weight |
15.4 kg |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| LAN controller |
Killer E3100G |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| WLAN controller manufacturer |
Intel |
| WLAN controller model |
Intel Wi-Fi 7 BE200 |
| Antenna type |
2x2 |
| Bluetooth |
Yes |
| Operating system/software |
| Operating system installed |
Windows 11 Home |
| Operating system architecture |
64-bit |
| Trial software |
Activate Your Microsoft 365 For A 30 Day Trial |
| Software |
| Operating system installed |
Windows 11 Home |
| Operating system architecture |
64-bit |
| Trial software |
Activate Your Microsoft 365 For A 30 Day Trial |
| Storage |
| Total storage capacity |
2 TB |
| Optical drive type |
No |
| Storage media |
SSD |
| Total SSDs capacity |
2 TB |
| Number of SSDs installed |
1 |
| SSD capacity |
2 TB |
| SSD interface |
PCI Express 4.0 |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| Expansion slots |
| PCI Express x4 (Gen 4.x) slots |
2 |
| PCI Express x16 (Gen 5.x) slots |
1 |
| Other features |
| Special features |
Clear Door & 240mm Liquid Cooler with AlienFX lighting |
| Graphics |
| Discrete graphics card |
Yes |
| On-board graphics card |
Yes |
| Discrete graphics card model |
NVIDIA GeForce RTX 5080 |
| On-board graphics card model |
Intel Graphics |
| Discrete graphics card memory |
16 GB |
| Discrete graphics memory type |
GDDR7 |
| Number of discrete graphics cards |
1 |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel Graphics |
| Graphics card HDMI ports quantity |
1 |
| Graphics card DisplayPorts quantity |
3 |
| Packaging content |
| Cables included |
AC |
| Design |
| Chassis type |
Desktop |
| Product colour |
Platinum |
| Placement supported |
Vertical |
| Water cooling system |
Yes |
| Cable lock slot |
Yes |
| Cable lock slot type |
Wedge |
| Viewing window |
Yes |
| Performance |
| Product type |
PC |
| Market positioning |
Gaming |
| Motherboard chipset |
Intel Z890 |
| Audio chip |
Realtek ALC1220 |
| Audio system |
High Definition Audio |
| Audio output channels |
5.1 channels |
| Neural processor unit (NPU) |
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to |
36 TOPs |
| NPU performance up to |
13 TOPs |
| GPU performance up to |
8 TOPs |
| Display |
| Display included |
No |
