Stock Status: 1x unit in stock
AP6020AFeatures
- Rack PDU, Basic, 0U/1U, 100-240V/20A, 220-240V/16A, (13) C13
- Reliable rack power distribution
- Includes : Installation guide , Safety guide
Marketing Features
Low Cost Power Distribution
Provides a number of outlets to bring power to rack equipment at an affordable price.
Wide range of input and output connections
Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
Single input power source
Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
Rack-Mountable
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Agility
Wide range of input and output connections
Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip.
Single input power source
Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections.
Rack-Mountable
Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment.
Total Cost of Ownership
Low Cost Power Distribution
Provides a number of outlets to bring power to rack equipment at an affordable price.
Specs
| Weight & dimensions |
| Dimensions (WxDxH) |
44 x 93 x 388 mm |
| Weight |
1.5 kg |
| Operational conditions |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-15 - 60 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating altitude |
0 - 3048 m |
| Power |
| Nominal input voltage |
100-240 V |
| Maximum current |
20 A |
| AC input frequency |
50 - 60 Hz |
| Load capacity |
3680 VA |
| Maximum input current per phase |
16 A |
| Maximum total current draw per phase |
16 A |
| Maximum power |
3680 W |
| Ports & interfaces |
| AC outlets quantity |
13 AC outlet(s) |
| Output connections |
IEC 320 C13 |
| Design |
| PDU types |
Basic |
| Rack capacity |
0U/1U |
| Mounting |
Horizontal/Vertical |
| Product colour |
Black |
| Technical details |
| Sustainability certificates |
RoHS |
| Features |
| Certification |
cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH |
| Packaging data |
| Package dimensions (WxDxH) |
210 x 76 x 436 mm |
| Package weight |
2.02 kg |
Features
APC AP6020A. PDU types: Basic, Rack capacity: 0U/1U, Mounting: Horizontal/Vertical. AC outlets quantity: 13 AC outlet(s), Output connections: IEC 320 C13. Certification: cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH. Nominal input voltage: 100-240 V, Maximum current: 20 A, AC input frequency: 50 - 60 Hz. Dimensions (WxDxH): 44 x 93 x 388 mm, Weight: 1.5 kg
