| Weight & dimensions |
| Width |
112 mm |
| Depth |
380 mm |
| Height |
301 mm |
| Weight |
12.7 kg |
| Package width |
238 mm |
| Package depth |
488 mm |
| Package height |
387 mm |
| Package weight |
14.3 kg |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-15 - 40 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 9000 m |
| Non-operating altitude |
0 - 15000 m |
| Power |
| Output power capacity |
1500 VA |
| Output power |
865 W |
| Input operation voltage (min) |
156 V |
| Input operation voltage (max) |
300 V |
| Power supply input frequency |
50/60 Hz |
| Surge energy rating |
441 J |
| Efficiency |
98.9% |
| Crest factor |
3:1 |
| Output frequency regulation |
50/60 Hz |
| Ports & interfaces |
| AC outlet types |
C13 coupler |
| AC outlets quantity |
10 AC outlet(s) |
| USB port |
Y |
| Number of output IEC jumpers |
2 |
| Power plug |
C14 coupler |
| Certificates |
| Certification |
A-tick, C-tick, CE, GOST, GS Mark, Telepermit, TUV, REACH, PEP, EOLI, NEMKO-GS |
| RoHS compliance |
Y |
| Energy Star certified |
Y |
| Other features |
| Nominal output voltage |
230 V |
| Nominal input voltage |
230 V |
| Packaging content |
1x Detachable IEC Power Cord |
| Battery |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Battery recharge time |
8 h |
| Typical backup time at half load |
12.4 min |
| Typical backup time at full load |
3.7 min |
| Replacement battery cartridge |
APCRBC124 |
| Hot-swap battery |
Y |
| Cold start |
Y |
| Automatic battery test |
Y |
| Battery life (max) |
5 year(s) |
| Battery capacity |
187 VAh |
| Packaging content |
| Bundled software |
PowerChute Personal Edition |
| Cables included |
Phone (RJ-11),USB cable |
| Manual |
Y |
| Warranty card |
Y |
| Software CD |
Y |
| Packaging content |
1x Detachable IEC Power Cord |
| Design |
| Colour of product |
Black |
| Display |
LCD |
| Product colour |
Black |
| Energy Star certified |
Y |
| RoHS compliance |
Y |
| Certification |
A-tick, C-tick, CE, GOST, GS Mark, Telepermit, TUV, REACH, PEP, EOLI, NEMKO-GS |
| Performance |
| UPS topology |
Line-Interactive |
| Hold time (min) |
10 ms |
| Hold time (max) |
12 ms |
| Surge protection |
Y |
| Surge protection features |
Digital Subscriber Line (DSL),Fax,Modem,Network,Telephone |
| Waveform |
Sine |
| Automatic Voltage Regulation (AVR) |
Y |
| Noise level |
45 dB |
| Audible alarm(s) |
Y |
| Audible alarm modes |
Low battery alarm,Overload alarm |
| Technical details |
| Input connections |
IEC-320 C14 |
| Features |
| UPS topology |
Line-Interactive |
| Output power capacity |
1.5 kVA |
| Output power |
865 W |
| Waveform |
Sine |
| Input operation voltage (min) |
156 V |
| Input operation voltage (max) |
300 V |
| Input frequency |
50/60 Hz |
| Output frequency regulation |
50/60 Hz |
| Automatic Voltage Regulation (AVR) |
Y |
| Surge energy rating |
441 J |
| Hold time (min) |
10 ms |
| Hold time (max) |
12 ms |
| Efficiency |
98.9% |
| Crest factor |
3:1 |
| Noise level |
45 dB |
| Surge protection |
Y |
| Surge protection features |
Digital Subscriber Line (DSL), Fax, Modem, Network, Telephone |
| Audible alarm(s) |
Y |
| Audible alarm modes |
Low battery alarm, Overload alarm |
| Logistics data |
| Quantity per pallet |
20 pc(s) |
| Quantity per master carton |
1 pc(s) |
| Quantity per master (outer) case |
1 pc(s) |
| Products per pallet |
20 pc(s) |
| Products per master (outer) case |
1 pc(s) |
| Packaging data |
| Cables included |
Phone (RJ-11), USB cable |
| Manual |
Y |
| Warranty card |
Y |
| Software CD |
Y |
| Bundled software |
PowerChute Personal Edition |
| Package width |
238 mm |
| Package depth |
488 mm |
| Package height |
387 mm |
| Package weight |
14.3 kg |
| Technical details |
| Sustainability certificates |
RoHS, ENERGY STAR |
