| Weight & dimensions |
| Width |
432 mm |
| Depth |
477 mm |
| Height |
86 mm |
| Weight |
28.2 kg |
| Package width |
594 mm |
| Package depth |
603 mm |
| Package height |
251 mm |
| Package weight |
31.4 kg |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-15 - 45 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 3000 m |
| Non-operating altitude |
0 - 15000 m |
| Ports & interfaces |
| AC outlet types |
C13 coupler |
| AC outlets quantity |
4 AC outlet(s) |
| USB port |
Y |
| USB port type |
USB Type-A |
| Serial interface |
Y |
| Serial interface type |
RJ-45 |
| Ethernet LAN (RJ-45) ports |
1 |
| SmartSlot |
Y |
| Battery |
| Battery technology |
Sealed Lead Acid (VRLA) |
| Number of batteries supported |
1 |
| Battery life (max) |
6 year(s) |
| Battery recharge time |
3 h |
| Hot-swap battery |
Y |
| Automatic battery test |
Y |
| Cold start |
Y |
| Replacement battery cartridge |
APCRBC132 |
| Design |
| Form factor |
Rackmount |
| Product colour |
Black |
| Rack capacity |
2U |
| Display type |
LCD |
| LED indicators |
Y |
| Certification |
EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, UL 1778, VDE, REACH |
| Features |
| UPS topology |
Line-Interactive |
| Output power capacity |
1 kVA |
| Output power |
700 W |
| Waveform |
Sine |
| Input operation voltage (min) |
151 V |
| Input operation voltage (max) |
302 V |
| Input frequency |
50/60 Hz |
| Output operation voltage (min) |
220 V |
| Output operation voltage (max) |
240 V |
| Output frequency |
50/60 Hz |
| Automatic Voltage Regulation (AVR) |
Y |
| Surge energy rating |
459 J |
| Response time |
10 ms |
| Output voltage Total Harmonic Distortion (THD) |
5% |
| Noise level |
45 dB |
| Surge protection |
Y |
| Web-based management |
Y |
| Auto-restart |
Y |
| Temperature voltage compensation |
Y |
| Logistics data |
| Products per pallet |
8 pc(s) |
| Harmonized System (HS) code |
85078000 |
| Packaging data |
| Rack mount kit |
Y |
| Cables included |
RS-232, USB cable |
| Quick installation guide |
Y |
| Resource CD |
Y |
| Software CD |
Y |
| Technical details |
| Sustainability certificates |
Green Premium, RoHS |
