Stock Status: 1x unit in stock
The Aruba 550 Series with 802.11ax (Wi-Fi 6), combined with Aruba intelligent software innovations are designed to deliver high performance connectivity for extreme high-density deployments of mobile and IoT.
The 550 Series is designed to simultaneously serve multiple clients and traffic types with dual radio (8x8 + 4x4 MIMO) and optional tri-radio mode, boosting overall network performance by up to 4X versus 802.11ac APs.
In addition to the benefits that 802.11ax delivers, the 550 Series provide differentiated capabilities which include AI-powered Wi-Fi RF optimization, always-on connectivity, WPA3 certified security, and unified wired and wireless policy with Dynamic Segmentation. Green AP mode offers AI-powered energy savings of up to 70%.
Enhanced performance
Aruba's ClientMatch feature intelligently groups Wi-Fi 6 clients onto the best AP's to leverage 802.11ax multi-user capabilities.
Smart power management
Aruba's unique Smart PoE allows for the use of existing switching infrastructure to power up APs
IoT and location ready
Leverage your Wi-Fi infrastructure to support Zigbee and Bluetooth devices and applications.
Specs
| Operational conditions |
| Operating relative humidity (H-H) |
5 - 93% |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-40 - 70 °C |
| Storage relative humidity (H-H) |
5 - 93% |
| Weight & dimensions |
| Width |
260 mm |
| Depth |
260 mm |
| Height |
58 mm |
| Weight |
1.57 kg |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
2 |
| USB 2.0 ports quantity |
1 |
| USB connector type |
USB Type-A |
| Power |
| Power over Ethernet (PoE) |
Y |
| Power consumption (max) |
38.2 W |
| Security |
| Security algorithms |
WMM,WPA,WPA2 |
| Antenna |
| Antenna type |
Internal |
| Antenna direction type |
Omni-directional |
| Antenna features |
Integrated antenna |
| Antennas quantity |
4 |
| Antenna gain level (max) |
5.5 dBi |
| Design |
| Placement |
Ceiling |
| Product colour |
White |
| Cable lock slot |
Y |
| Cable lock slot type |
Kensington |
| Features |
| 2.4 GHz |
Y |
| 5 GHz |
Y |
| Maximum data transfer rate |
5950 Mbit/s |
| Maximum data transfer rate (2.4 GHz) |
1150 Mbit/s |
| Maximum data transfer rate (5 GHz) |
4800 Mbit/s |
| Ethernet LAN data rates |
100,1000,2500,5000 Mbit/s |
| Networking standards |
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3bt,IEEE 802.3bz |
| Auto MDI/MDI-X |
Y |
| MIMO |
Y |
| Spread spectrum method |
DSSS,OFDM |
| Modulation |
16PSK,64-QAM,256-QAM,1024-QAM,BPSK,CCK,QPSK |
Features
Hewlett Packard Enterprise Aruba AP-555 (RW). Maximum data transfer rate: 5950 Mbit/s, Maximum data transfer rate (2.4 GHz): 1150 Mbit/s, Maximum data transfer rate (5 GHz): 4800 Mbit/s. Security algorithms: WMM,WPA,WPA2. USB connector type: USB Type-A. Power consumption (max): 38.2 W. Placement: Ceiling, Product colour: White, Cable lock slot type: Kensington
Product Description
The Aruba 550 Series with 802.11ax (Wi-Fi 6), combined with Aruba intelligent software innovations are designed to deliver high performance connectivity for extreme high-density deployments of mobile and IoT.
The 550 Series is designed to simultaneously serve multiple clients and traffic types with dual radio (8x8 + 4x4 MIMO) and optional tri-radio mode, boosting overall network performance by up to 4X versus 802.11ac APs.
In addition to the benefits that 802.11ax delivers, the 550 Series provide differentiated capabilities which include AI-powered Wi-Fi RF optimization, always-on connectivity, WPA3 certified security, and unified wired and wireless policy with Dynamic Segmentation. Green AP mode offers AI-powered energy savings of up to 70%.
Enhanced performance
Aruba's ClientMatch feature intelligently groups Wi-Fi 6 clients onto the best AP's to leverage 802.11ax multi-user capabilities.
Smart power management
Aruba's unique Smart PoE allows for the use of existing switching infrastructure to power up APs
IoT and location ready
Leverage your Wi-Fi infrastructure to support Zigbee and Bluetooth devices and applications.
