| Processor |
| Processor family |
Intel Core Ultra 9 |
| Processor manufacturer |
Intel |
| Processor model |
275HX |
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor cores |
24 |
| Processor threads |
24 |
| Processor boost frequency |
5.4 GHz |
| Performance cores |
8 |
| Efficient cores |
16 |
| Performance-core Max Turbo Frequency |
5.4 GHz |
| Efficient-core Max Turbo Frequency |
4.6 GHz |
| Performance-core base frequency |
2.7 GHz |
| Efficient-core base frequency |
2.1 GHz |
| Processor cache |
36 MB |
| Processor base power |
55 W |
| Maximum turbo power |
160 W |
| Memory |
| Internal memory |
32 GB |
| Maximum internal memory |
32 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory slots |
2x SO-DIMM |
| Memory clock speed |
6400 MHz |
| Supported memory types |
DDR5-SDRAM |
| Ports & interfaces |
| USB 2.0 ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
6 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Thunderbolt 3 ports quantity |
0 |
| HDMI ports quantity |
2 |
| Intel® Thunderbolt 4 |
Yes |
| Thunderbolt 4 ports quantity |
1 |
| DisplayPorts quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| Weight & dimensions |
| Width |
282.4 mm |
| Depth |
187.7 mm |
| Height |
56.5 mm |
| Weight |
3.12 kg |
| Package width |
370 mm |
| Package depth |
258 mm |
| Package height |
190 mm |
| Package weight |
5.6 kg |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Ethernet LAN data rates |
2500 Mbit/s |
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| WLAN controller model |
Intel Wi-Fi 7 BE200 |
| Bluetooth |
Yes |
| Bluetooth version |
5.4 |
| Operating system/software |
| Operating system installed |
Windows 11 Home |
| Operating system architecture |
64-bit |
| Software |
| Operating system installed |
Windows 11 Home |
| Operating system architecture |
64-bit |
| Storage |
| Total storage capacity |
1 TB |
| Optical drive type |
No |
| Storage media |
SSD |
| Total SSDs capacity |
1 TB |
| Number of SSDs installed |
1 |
| SSD capacity |
1 TB |
| SSD interface |
PCI Express 4.0 |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| M.2 SSD size |
2280 (22 x 80 mm) |
| Compatible memory cards |
SD |
| Other features |
| Power supply type |
External AC adapter |
| Graphics |
| Discrete graphics card |
Yes |
| On-board graphics card |
Yes |
| Discrete graphics card model |
NVIDIA GeForce RTX 5070 |
| On-board graphics card model |
Intel Graphics |
| Discrete GPU manufacturer |
NVIDIA |
| Discrete graphics memory type |
GDDR7 |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel Graphics |
| Packaging content |
| Cables included |
Power |
| Design |
| Chassis type |
Mini PC |
| Product colour |
Black |
| Performance |
| Product type |
Mini PC |
| Market positioning |
Gaming |
| Neural processor unit (NPU) |
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to |
36 TOPs |
| NPU performance up to |
13 TOPs |
| GPU performance up to |
8 TOPs |
| Display |
| Display included |
No |
