Stock Status: 1x unit in stock
Features
- 4-port KVM switch with USB 2.0 support and 2.1 surround sound audio
- One console controls four computers and two additional USB devices
- 2-port USB 2.0 hub built in
- USB 2.0 compliant
- Dual interface - supports computers with PS/2 or USB keyboard and mouse configurations
- Audio enabled - full bass response provides a rich experience for 2.1 surround sound systems
- Console audio ports on front panel for easy access - ideal for IP phone users
- Supports both USB and PS/2 keyboards and mice - flexible configurations available with the included USB-to-PS/2 converter: USB keyboard and mouse; PS/2 keyboard and mouse; or PS/2 keyboard and USB mouse
- Independent switching of KVM, USB, and Audio focus
- Superior video quality; 2048 x 1536; DDC2B
- Supports widescreen resolutions
- Computer selection via front panel pushbuttons, multilingual OSD (On Screen Display), and mouse
- Multiplatform support - Windows , Mac, and Sun
- Console mouse port emulation / bypass feature supports full mouse driver and multifunction mice
- Video DynaSync™ - stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution
- Complete keyboard emulation for error-free booting
- Sun/Mac keyboard support and emulation*
- Auto Scan Mode for monitoring all computers
- LED Display for easy status monitoring
- Easy installation no software required
- Firmware upgradeable
*1.PC keyboard combinations emulate Sun/Mac keyboards
*2.Sun/Mac keyboards only work with their own computers
Package Contents
- 1x 4-Port USB 2.0 KVMP™ Switch
- 2x 2L-5301U USB KVM Cables
- 2x 2L-5302U USB KVM Cables
- 1x UC20KMZ-A-11 USB-to-PS/2 Converter
- 2x OSD/Hotkey Stickers
- 1x Firmware Upgrade Cable
- 1x 0AD6-1605-24EG Power Adapter
- 1x User Instructions
Specs
| Ports & interfaces |
| Number of computers controlled |
4 |
| Keyboard port type |
USB |
| Mouse port type |
USB |
| Video port type |
VGA |
| USB 2.0 Type-A hub ports quantity |
4 |
| USB connector type |
USB Type-A |
| Audio connections |
Yes |
| Headphone outputs |
5 |
| Number of microphone inputs |
5 |
| Weight & dimensions |
| Width |
210 mm |
| Depth |
88 mm |
| Height |
55.5 mm |
| Weight |
780 g |
| Operational conditions |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
0 - 80% |
| Power |
| Power source |
DC |
| Output voltage |
5.3 V |
| Power consumption (typical) |
3.4 W |
| External power adapter |
Yes |
| Display |
| Built-in display |
No |
| Design |
| Rack mounting |
Yes |
| Product colour |
Black, Grey |
| Housing material |
Metal |
| Wired remote switch |
No |
| LED indicators |
Activity, USB |
| Display switch button |
Yes |
| Hot keys |
Yes |
| Performance |
| HD type |
2K Ultra HD |
| Maximum resolution |
2048 x 1536 pixels |
| Maximum digital resolution |
2048 x 1536 pixels |
| Video bandwidth |
60 Hz |
| Scan interval |
1,3,4,5,8,10,15,20,25,30,35,40,45,50,55,60,70,80,90,99,100,240,250,255 s |
| Firmware upgradeable |
Yes |
| Logistics data |
| Harmonized System (HS) code |
85176200 |
Features
ATEN CS1734B. Keyboard port type: USB, Mouse port type: USB, Video port type: VGA. HD type: 2K Ultra HD, Maximum resolution: 2048 x 1536 pixels, Maximum digital resolution: 2048 x 1536 pixels. Product colour: Black, Grey, Housing material: Metal, LED indicators: Activity, USB. Power source: DC, Output voltage: 5.3 V, Power consumption (typical): 3.4 W. Width: 210 mm, Depth: 88 mm, Height: 55.5 mm
Product Description
Features
- 4-port KVM switch with USB 2.0 support and 2.1 surround sound audio
- One console controls four computers and two additional USB devices
- 2-port USB 2.0 hub built in
- USB 2.0 compliant
- Dual interface - supports computers with PS/2 or USB keyboard and mouse configurations
- Audio enabled - full bass response provides a rich experience for 2.1 surround sound systems
- Console audio ports on front panel for easy access - ideal for IP phone users
- Supports both USB and PS/2 keyboards and mice - flexible configurations available with the included USB-to-PS/2 converter: USB keyboard and mouse; PS/2 keyboard and mouse; or PS/2 keyboard and USB mouse
- Independent switching of KVM, USB, and Audio focus
- Superior video quality; 2048 x 1536; DDC2B
- Supports widescreen resolutions
- Computer selection via front panel pushbuttons, multilingual OSD (On Screen Display), and mouse
- Multiplatform support - Windows , Mac, and Sun
- Console mouse port emulation / bypass feature supports full mouse driver and multifunction mice
- Video DynaSync™ - stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution
- Complete keyboard emulation for error-free booting
- Sun/Mac keyboard support and emulation*
- Auto Scan Mode for monitoring all computers
- LED Display for easy status monitoring
- Easy installation no software required
- Firmware upgradeable
*1.PC keyboard combinations emulate Sun/Mac keyboards
*2.Sun/Mac keyboards only work with their own computers
Package Contents
- 1x 4-Port USB 2.0 KVMP™ Switch
- 2x 2L-5301U USB KVM Cables
- 2x 2L-5302U USB KVM Cables
- 1x UC20KMZ-A-11 USB-to-PS/2 Converter
- 2x OSD/Hotkey Stickers
- 1x Firmware Upgrade Cable
- 1x 0AD6-1605-24EG Power Adapter
- 1x User Instructions
