Stock Status: 1x unit in stock
The ATEN VS482B Switch is an ideal solution for application requiring superior video resolution of True 4K when connecting 4 HDMI A/V sources to 2 HDMI displays. Complying with HDMI 2.0 standards, the switch's Audio Return Channel (ARC) function allows users to send audio without having to attach a separate audio cable.
1x VS482B 4-Port True 4K HDMI Switch with Dual Output
1x 0AD8-1005-26M1 Power Adapter
1x 2XRT-0010G IR Remote Control Unit
1x Mounting Kit
1x User Instructions
Specs
| Packaging content |
| Mounting kit |
Yes |
| AC adapter included |
Yes |
| Technical details |
| Compliance certificates |
RoHS |
| Ports & interfaces |
| Video port type |
HDMI |
| HDMI ports quantity |
6 |
| HDMI version |
2.0 |
| HDMI in |
4 |
| Number of HDMI outputs |
2 |
| RS-232 ports |
1 |
| DC-in jack |
Yes |
| Weight & dimensions |
| Width |
158.8 mm |
| Depth |
437.2 mm |
| Height |
44 mm |
| Weight |
2.16 kg |
| Power |
| Power consumption (typical) |
3.29 W |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
0 - 80% |
| Packaging data |
| Package width |
116 mm |
| Package depth |
540 mm |
| Package height |
233 mm |
| Package weight |
2.84 kg |
| Features |
| Material |
Metal |
| Product colour |
Black |
| Consumer Electronics Control (CEC) support |
Yes |
| HDCP |
Yes |
| Maximum refresh rate |
60 Hz |
| Maximum operating distance |
3 m |
| Supported graphics resolutions |
3840 x 2160, 4096 x 2160 |
| Bandwidth |
600 MHz |
| LED indicators |
Yes |
| Maximum resolution |
4096 x 2160 pixels |
| 3D |
Yes |
| HD type |
4K Ultra HD |
| Input impedance |
100 Ω |
| Output impedance |
100 Ω |
| HDCP version |
2.2 |
Features
ATEN VS482B-AT-E. Video port type: HDMI. Material: Metal, Product colour: Black, Maximum refresh rate: 60 Hz. Power consumption (typical): 3.29 W. Width: 158.8 mm, Depth: 437.2 mm, Height: 44 mm. Package width: 116 mm, Package depth: 540 mm, Package height: 233 mm
Product Description
The ATEN VS482B Switch is an ideal solution for application requiring superior video resolution of True 4K when connecting 4 HDMI A/V sources to 2 HDMI displays. Complying with HDMI 2.0 standards, the switch's Audio Return Channel (ARC) function allows users to send audio without having to attach a separate audio cable.
1x VS482B 4-Port True 4K HDMI Switch with Dual Output
1x 0AD8-1005-26M1 Power Adapter
1x 2XRT-0010G IR Remote Control Unit
1x Mounting Kit
1x User Instructions
