| Weight & dimensions |
| Width |
202.5 mm |
| Depth |
218.5 mm |
| Height |
250.7 mm |
| Weight |
3.6 kg |
| Packaging data |
| Package width |
389 mm |
| Package depth |
278 mm |
| Package height |
310 mm |
| Package weight |
6.6 kg |
| Camera |
| Megapixel (approx.) |
8 MP |
| Camera type |
Dual camera |
| Second camera resolution |
8 MP |
| Sensor type |
Exmor CMOS |
| Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") |
| Zoom capability |
Yes |
| Optical zoom |
30x |
| Digital zoom |
1x |
| Combined zoom |
30x |
| Focal length range |
4.5 - 135 mm |
| Field of view (wide) |
69.2° |
| Field of view (tele) |
2.8° |
| Second camera field of view (FOV) angle |
113° |
| Horizontal field of view (wide) |
62.3° |
| Horizontal field of view (tele) |
2.5° |
| Vertical field of view (wide) |
37.3° |
| Vertical field of view (tele) |
1.4° |
| Minimum illumination |
0.5 lx |
| Signal-to-Noise Ratio (SNR) |
50 dB |
| Flip & mirror |
Yes |
| Second camera F-number |
2.22 |
| Aperture range (F-F) |
1.8 - 4.7 |
| White balance |
ATW, Auto, Indoor, Manual, One push, Outdoor |
| Auto exposure |
Yes |
| Light exposure modes |
Aperture priority AE, Shutter priority AE, IRIS priority AE |
| Closest focusing distance |
0.1 m |
| Second camera lens type |
Wide-angle |
| Wide Dynamic Range (WDR) |
Yes |
| Back Light Compensation (BLC) |
Yes |
| Gain control type |
Auto/Manual |
| PTZ control |
Yes |
| PTZ protocols |
CGI, ONVIF, Pelco-P/D, UAC, UVC, VISCA |
| Slowest camera shutter speed |
1 s |
| Fastest camera shutter speed |
1/10000 s |
| 3D NR (Noise Reduction) |
Yes |
| Face tracking |
Yes |
| Voice tracking |
Yes |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
20 - 95% |
| Power |
| Power source type |
DC, PoE |
| AC input frequency |
50/60 Hz |
| AC input voltage |
100 - 240 V |
| DC input voltage |
12 V |
| Input current |
5 A |
| Video |
| Maximum video resolution |
3840 x 2160 pixels |
| Maximum frame rate |
60 fps |
| HD type |
4K Ultra HD |
| Resolution at capture speed |
1280x720@50fps, 1280x720@60fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@25fps, 3840x2160@30fps, 3840x2160@60fps |
| Video formats supported |
H.264, H.265, M-JPEG |
| Number of TV lines |
1600 |
| Ports & interfaces |
| HDMI ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity |
1 |
| RS-232 ports |
1 |
| RS-422 ports |
1 |
| DC-in jack |
Yes |
| 3G-SDI output |
Yes |
| Microphone in |
Yes |
| Line-in |
Yes |
| Design |
| Product colour |
Black |
| Tilt angle range |
-30 - 90° |
| Pan range |
-170 - 170° |
| LED indicators |
Power |
| Tally light |
Yes |
| Web-based management |
Yes |
| Tilt speed (min) |
0.1 °/sec |
| Tilt speed (max) |
100 °/sec |
| Tilt preset speed |
200 °/sec |
| Pan speed (min) |
0.1 °/sec |
| Pan speed (max) |
100 °/sec |
| Pan preset speed |
200 °/sec |
| Country of origin |
Taiwan |
| Packaging content |
| Remote control included |
Yes |
| Packaging content |
Camera, Remote Control, RS-232 In/Out Cable, Din 8 To D-Sub 9 Cable, Power Adapter, Power Cord, Cable Tie (x7), M2 x 4 mm Screw (x5), M3 x 6 mm Screw (x3), 1/4"-20L 6.5mm Screw (x2), Cable Fixing Plate (x2), Ceiling Mount Bracket (x2), Drilling Paper, Qui |
| System requirements |
| Windows operating systems supported |
Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1 |
| Mac operating systems supported |
Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura, Mac OS X 14.0 Sonoma |
| Mobile operating systems supported |
iOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 13, iOS 13.4, iOS 14, iOS 14.5, iOS 15, iOS 16, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3, iPadOS, iPadOS 13, iPadOS 14, iPadOS 17.1.1, iPadOS 17.4, iPadOS 17.5 |
| Performance |
| Live video preview |
Yes |
| Auto-tracking |
Yes |
| Tracking modes |
Presenter mode, Zone mode |
| Remote control function |
Yes |
| Remote control type |
IR |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Audio |
| Built-in speaker(s) |
Yes |
| Supported sample rates |
48 kHz |
| Audio codecs |
AAC-LC (48K) |
| Technical details |
| Warranty period |
5 year(s) |
| Network |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| Streaming capability |
Yes |
| Network streaming |
Yes |
| Bit rate control |
Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Bit rate range |
512 - 64000 Kbit/s |
| Supported network protocols |
IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, RTP / RTCP, RTSP, RTMP, SRT, HLS, NDI, LLDP, VISCA over IP |
| Logistics data |
| Products per master (outer) case |
1 pc(s) |
| Products per pallet |
42 pc(s) |
| Harmonized System (HS) code |
8525801990 |
| Certification |
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS |
