| Weight & dimensions |
| Width |
305 mm |
| Depth |
244 mm |
| Height |
70 mm |
| Memory |
| Supported memory types |
DDR4-SDRAM |
| Number of memory slots |
4 |
| Maximum internal memory |
128 GB |
| Memory slots type |
DIMM |
| ECC |
Y |
| Non-ECC |
Y |
| Supported memory clock speeds |
2133,2400,2666,2933,3000,3200,3300,3333,3400,3466,3600,3666,3733,3800,3866,4000,4133,4266,4300,4400,4500,4600,4700,4800,4933,5000,5133,5333 MHz |
| Unbuffered memory |
Y |
| Processor |
| Processor manufacturer |
Intel |
| Processor socket |
LGA 1700 |
| Compatible processor series |
Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9 |
| Maximum number of SMP processors |
1 |
| Back panel I/O ports |
| USB 2.0 ports quantity |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
1 |
| USB 3.2 Gen 2x2 Type-C ports quantity |
1 |
| HDMI version |
2.0 |
| DisplayPorts quantity |
1 |
| DisplayPort version |
1.2 |
| WiFi-AP antenna jack |
2 |
| Internal I/O |
| USB 2.0 connectors |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
1 |
| Number of SATA III connectors |
4 |
| Front panel audio connector |
Y |
| Front panel connector |
Y |
| ATX Power connector (24-pin) |
Y |
| CPU fan connector |
Y |
| Number of chassis fan connectors |
4 |
| Thunderbolt headers |
2 |
| 12V power connector |
Y |
| RGB LED pin header |
Y |
| Networking |
| Wi-Fi |
Y |
| Ethernet LAN |
Y |
| Ethernet interface type |
2.5 Gigabit Ethernet |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Wi-Fi standards |
802.11a, 802.11ad, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Bluetooth |
Y |
| Bluetooth version |
5.2 |
| Expansion slots |
| PCI Express x16 slots |
3 |
| Number of M.2 (M) slots |
3 |
| Packaging content |
| Cables included |
SATA |
| Drivers included |
Y |
| Bundled software |
Norton Internet Security
cFosSpeed |
| BIOS |
| BIOS type |
EFI AMI |
| BIOS memory size |
256 Mbit |
| ACPI version |
5.0 |
| Clear CMOS jumper |
Y |
| Desktop Management Interface (DMI) version |
2.7 |
| System Management BIOS (SMBIOS) version |
2.7 |
| Other features |
| Weight |
1 kg |
| Graphics |
| Parallel processing technology support |
2-Way CrossFireX, Quad-GPU CrossFireX |
| Maximum resolution |
4096 x 2160 pixels |
| HDCP |
Y |
| Features |
| Component for |
PC |
| Motherboard form factor |
ATX |
| Motherboard chipset family |
Intel |
| Motherboard chipset |
Intel B660 |
| Audio output channels |
7.1 channels |
| Audio chip |
Realtek ALC1220-VB |
| PC health monitoring |
Fan, Temperature, Voltage |
| Windows operating systems supported |
Windows 10 x64, Windows 11 x64 |
| Harmonized System (HS) code |
84733020 |
| Storage controllers |
| Supported storage drive interfaces |
M.2, SATA III |
| Supported storage drive types |
HDD & SSD |
| RAID support |
Y |
| RAID levels |
0, 1, 5, 10 |
