| Weight & dimensions |
| Weight |
2.6 kg |
| Width |
287.3 mm |
| Depth |
232.6 mm |
| Height |
114.4 mm |
| Operational conditions |
| Operating temperature (T-T) |
0 - 40 °C |
| Projector |
| Projector brightness |
3200 ANSI lumens |
| Projection technology |
DLP |
| Projector native resolution |
WXGA (1280x800) |
| Native aspect ratio |
16:10 |
| Screen size compatibility |
762 - 7620 mm (30 - 300") |
| Contrast ratio (dynamic) |
13000:1 |
| Number of colours |
1.073 billion colours |
| Horizontal scan range |
15 - 102 kHz |
| Vertical scan range |
24 - 120 Hz |
| Keystone correction, horizontal |
-30 - 30° |
| Horizontal synchronization (min) |
15 kHz |
| Horizontal synchronization (max) |
102 kHz |
| Vertical synchronization (min) |
0.024 kHz |
| Vertical synchronization (max) |
0.12 kHz |
| Video |
| Analog signal format system |
SECAM, NTSC, PAL |
| Full HD |
No |
| 3D |
Yes |
| Supported 3D formats |
Frame Sequential, Top and bottom |
| Supported graphics resolutions |
640 x 480 (VGA), 1600 x 1200 (UXGA) |
| Supported video modes |
576i, 480i, 576p, 1080i, 480p, 1080p, 720p |
| Video processing |
30 bit |
| Display |
| Built-in display |
Yes |
| Display number of colours |
1.073 billion colours |
| Lens system |
| Focal length range |
10.2 - 12.24 mm |
| Aperture range (F-F) |
2.6 - 2.78 |
| Zoom ratio |
1.2:1 |
| Throw ratio |
0.72 - 0.87:1 |
| Vertical lens shift range |
-30 - 30% |
| Offset |
105% |
| Power |
| Power source |
AC |
| Power consumption (typical) |
305 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (PowerSave) |
220 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Ports & interfaces |
| VGA (D-Sub) ports quantity |
2 |
| HDMI ports quantity |
2 |
| DVI port |
No |
| USB 2.0 ports quantity |
1 |
| Audio (L/R) in |
1 |
| Serial interface type |
RS-232 |
| HDMI version |
1.4a |
| S-Video inputs quantity |
1 |
| Mini-USB 2.0 ports quantity |
1 |
| Microphone in |
No |
| PC Audio in |
Yes |
| PC Audio out |
Yes |
| PC in (D-Sub) |
Yes |
| USB connector type |
USB Type-A, Mini-USB B |
| Mobile High-Definition Link (MHL) |
Yes |
| Composite video in |
0 |
| Component video (YPbPr/YCbCr) in |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
0 |
| Composite video out |
0 |
| Networking |
| Ethernet LAN |
No |
| Wi-Fi |
No |
| Bluetooth |
No |
| Ethernet LAN (RJ-45) ports |
0 |
| Storage |
| Card reader integrated |
Yes |
| Packaging content |
| Remote control included |
Yes |
| Remote control type |
IR |
| Batteries included |
Yes |
| Cables included |
AC, VGA |
| Quick start guide |
Yes |
| Manual |
Yes |
| Warranty card |
Yes |
| Other features |
| RS-232 ports |
1 |
| Design |
| Product type |
Standard throw projector |
| Market positioning |
Business |
| Product colour |
White |
| Placement |
Desktop |
| Cable lock slot |
Yes |
| Multimedia |
| Built-in speaker(s) |
Yes |
| RMS rated power |
10 W |
| Number of built-in speakers |
1 |
| Technical details |
| Operating time |
4000 h |
| Features |
| Noise level |
33 dB |
| Noise level (economic mode) |
28 dB |
| HDCP |
No |
| On Screen Display (OSD) |
Yes |
| On Screen Display (OSD) languages |
Arabic, Dutch, Norwegian, Bulgarian, English, Indonesian, Italian, Polish, Swedish, Japanese, Portuguese, Thai, Finnish, Romanian, Turkish, Croatian, French, Korean, Russian, Czech, Greek, Danish, Hungarian |
| Number of OSD languages |
28 |
| Light source |
| Light source type |
Lamp |
| Service life of light source |
4500 h |
| Service life of light source (economic mode) |
6000 h |
| Lamp power |
196 W |
