| Weight & dimensions |
| Width |
243 mm |
| Depth |
320 mm |
| Height |
391 mm |
| Weight |
3.17 kg |
| Ports & interfaces |
| USB port |
Yes |
| USB version |
2.0 |
| System requirements |
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Server operating systems supported |
Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Power |
| Power supply type |
AC |
| Power consumption (typical) |
25 W |
| Power consumption (standby) |
7.3 W |
| Power consumption (off) |
0.1 W |
| Power consumption (sleep) |
1.7 W |
| Scanning |
| Maximum scan size |
215.9 x 355.6 mm |
| Optical scanning resolution |
600 x 600 DPI |
| Duplex scanning |
Yes |
| Enhanced scan resolution |
1200 x 1200 DPI |
| Colour scanning |
Yes |
| Greyscale levels |
256 |
| ADF scan speed (b/w, A4) |
35 ppm |
| ADF scan speed (colour, A4) |
35 ppm |
| Duplex ADF scan speed (b/w, A4) |
70 ipm |
| Duplex ADF scan speed (colour, A4) |
70 ipm |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Paper handling |
| Maximum ISO A-series paper size |
A4 |
| Scanning media types supported |
Business Card, Plain paper, Plastic Card, Recycled paper, Thick paper, Thin paper |
| Card thickness (max) |
1.1 mm |
| Auto Document Feeder (ADF) media weight |
40 - 200 g/m² |
| Maximum scan width |
21.6 cm |
| Maximum scan length |
35.6 cm |
| Input capacity |
| Auto document feeder (ADF) input capacity |
60 sheets |
| Other features |
| Spare part retention |
5 year(s) |
| Design |
| Scanner type |
ADF scanner |
| Built-in display |
Yes |
| Product colour |
Black, White |
| Display diagonal |
7.11 cm (2.8") |
| Touchscreen |
Yes |
| Colour display |
Yes |
| Control type |
Buttons, Touch |
| Packaging content |
| Cables included |
AC, USB |
| Performance |
| Scan to |
E-mail Server, FTP, Image, PC, SMB |
| Scan drivers |
SANE, WIA |
| Scanning noise level |
59 dB |
| Technical details |
| Pallet type |
800 x 1200 mm |
| Networking |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN |
Yes |
| Security algorithms |
AES, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, PEAP, SMTP-AUTH, SNMPv3, SSL/TLS, TKIP, TLS, WEP, WPA-PSK, WPA2-PSK, WPA3 |
| IPv6 support |
Yes |
| Logistics data |
| Products per pallet |
50 pc(s) |
| Country of origin |
China |
| Master (outer) cases per pallet |
50 pc(s) |
| Layers per pallet |
5 pc(s) |
| Pallet gross weight |
205 kg |
| Pallet gross height |
17.5 cm |
| Master (outer) cases per pallet layer |
10 pc(s) |
| Harmonized System (HS) code |
84716070 |
| Packaging data |
| Package width |
391 mm |
| Package depth |
320 mm |
| Package height |
243 mm |
| Package weight |
3.82 kg |
