Stock Status: 1x unit in stock
Print quotations, invoices, and other reports whilst on the move and streamline the work of field sales, field service, logistics, delivery and the emergency service sectors. The PJ-863 supports both charging and data transfer via USB-C, as well as Bluetooth connectivity to provide a mobile A4 print solution which is compact enough to fit easily into a briefcase or computer bag, but that can also be permanently installed in vehicles. Thermal print technology at 300x300dpi produces high-resolution, crisp text at a print speed of up to 13.5 pages per minute. Compatible with a wide range of mobile and desktop operating systems, the PJ-863 can easily be integrated into your own apps and software using the various SDK's (Software Development Kits) available. Also supports a variety of printer command languages, including ZPL2 emulation.
Specs
| Weight & dimensions |
| Width |
255 mm |
| Depth |
55 mm |
| Height |
30 mm |
| Weight |
480 g |
| Ports & interfaces |
| Connectivity technology |
Wired & Wireless |
| USB port |
Yes |
| USB connector |
USB Type-C |
| Bluetooth |
Yes |
| Bluetooth version |
5.2 |
| Bluetooth Low Energy (BLE) |
Yes |
| Bluetooth profiles |
GATT, HCRP, OPP, SSP |
| Paper handling |
| Printing media thickness |
160 µm |
| Maximum printing width |
20.3 cm |
| Power |
| Power source type |
USB |
| Features |
| Built-in barcodes |
Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, ITF, Industrial 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, Standard 2/5, UPC-A, UPC-E |
| Internal memory |
256 MB |
| Flash memory |
64 MB |
| Design |
| Product colour |
Black |
| Built-in display |
No |
| System requirements |
| Windows operating systems supported |
Yes |
| Mac compatibility |
Yes |
| Mac operating systems supported |
Yes |
| Mobile operating systems supported |
Android |
| Linux operating systems supported |
Yes |
| Printing |
| Print technology |
Direct thermal |
| Type |
Mobile printer |
| Maximum resolution |
300 x 300 DPI |
| Printing characters |
2D barcode, Barcode, Text |
Features
Brother PJ863. Print technology: Direct thermal, Type: Mobile printer, Maximum resolution: 300 x 300 DPI. Printing media thickness: 160 µm, Maximum printing width: 20.3 cm. Connectivity technology: Wired & Wireless, USB connector: USB Type-C, Bluetooth profiles: GATT, HCRP, OPP, SSP. Built-in barcodes: Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar,..., Internal memory: 256 MB, Flash memory: 64 MB. Product colour: Black
Product Description
Print quotations, invoices, and other reports whilst on the move and streamline the work of field sales, field service, logistics, delivery and the emergency service sectors. The PJ-863 supports both charging and data transfer via USB-C, as well as Bluetooth connectivity to provide a mobile A4 print solution which is compact enough to fit easily into a briefcase or computer bag, but that can also be permanently installed in vehicles. Thermal print technology at 300x300dpi produces high-resolution, crisp text at a print speed of up to 13.5 pages per minute. Compatible with a wide range of mobile and desktop operating systems, the PJ-863 can easily be integrated into your own apps and software using the various SDK's (Software Development Kits) available. Also supports a variety of printer command languages, including ZPL2 emulation.
