| Processor |
| Processor family |
Intel® Core™ i5 |
| Processor manufacturer |
Intel |
| Processor model |
i5-10505 |
| Processor frequency |
3.2 GHz |
| Processor generation |
10th gen Intel® Core™ i5 |
| Processor cores |
6 |
| Processor boost frequency |
4.6 GHz |
| Processor cache |
12 MB |
| Number of processors installed |
1 |
| Memory |
| Internal memory |
8 GB |
| Maximum internal memory |
128 GB |
| Internal memory type |
DDR4-SDRAM |
| Memory layout (slots x size) |
1 x 8 GB |
| Memory slots |
4x DIMM |
| Memory clock speed |
2666 MHz |
| Ports & interfaces |
| USB 2.0 ports quantity |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Number of USB ports with PowerShare support |
1 |
| DisplayPorts quantity |
2 |
| DisplayPort version |
1.4 |
| Ethernet LAN (RJ-45) ports |
1 |
| Line-out |
Y |
| Line-in |
Y |
| Combo headphone/mic port |
Y |
| Number of SATA III connectors |
3 |
| Power |
| Power supply |
200 W |
| Power supply input voltage |
90 - 264 V |
| Power supply input frequency |
47/63 Hz |
| Operational conditions |
| Operating temperature (T-T) |
10 - 35 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating altitude |
0 - 3048 m |
| Non-operating altitude |
0 - 10668 m |
| Weight & dimensions |
| Width |
92.6 mm |
| Depth |
292.8 mm |
| Height |
290 mm |
| Weight |
5.65 kg |
| Networking |
| Ethernet LAN |
Y |
| Wi-Fi |
N |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| LAN controller |
Intel® I219 |
| Operating system/software |
| Operating system installed |
Windows 10 Pro |
| Operating system architecture |
64-bit |
| Windows 11 free upgrade |
Y |
| Operating system language |
Multilingual |
| Trial software |
Microsoft Office Trial |
| Software |
| Operating system installed |
Windows 10 Pro |
| Operating system architecture |
64-bit |
| Windows 11 free upgrade |
Y |
| Operating system language |
Multilingual |
| Trial software |
Microsoft Office Trial |
| Storage |
| Total storage capacity |
256 GB |
| Optical drive type |
DVD±RW |
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| Total SSDs capacity |
256 GB |
| Number of SSDs installed |
1 |
| SSD capacity |
256 GB |
| SSD interface |
NVMe, PCI Express |
| SSD form factor |
M.2 |
| Expansion slots |
| PCI Express x4 (Gen 3.x) slots |
1 |
| PCI Express x16 (Gen 3.x) slots |
1 |
| Other features |
| Harmonized System (HS) code |
84715000 |
| Graphics |
| Discrete graphics card |
N |
| On-board graphics card |
Y |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel® UHD Graphics 630 |
| Packaging content |
| Display included |
N |
| Mouse included on selected markets only |
Y |
| Keyboard included on selected markets only |
Y |
| Input device model |
KB216 + MS116 |
| Processor special features |
| Intel 64 |
Y |
| Enhanced Intel SpeedStep Technology |
Y |
| Intel Clear Video Technology |
Y |
| Intel VT-x with Extended Page Tables (EPT) |
Y |
| Idle States |
Y |
| Intel Stable Image Platform Program (SIPP) |
Y |
| Intel Trusted Execution Technology |
Y |
| Execute Disable Bit |
Y |
| Intel Software Guard Extensions (Intel SGX) |
Y |
| CPU configuration (max) |
1 |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
| Intel Virtualization Technology (VT-x) |
Y |
| Design |
| Chassis type |
SFF |
| Product colour |
Black |
| Placement supported |
Horizontal/Vertical |
| Cable lock slot |
Y |
| Cable lock slot type |
Kensington |
| Performance |
| Product type |
PC |
| Market positioning |
Business |
| Motherboard chipset |
Intel Q570 |
| Audio system |
Waves MaxxAudio |
| Password protection |
Y |
| Trusted Platform Module (TPM) |
Y |
