| Processor |
| Processor family |
Intel Xeon W |
| Processor manufacturer |
Intel |
| Processor model |
w3-2425 |
| Processor frequency |
3 GHz |
| Processor cores |
6 |
| Performance cores |
6 |
| Processor boost frequency |
4.4 GHz |
| Processor cache |
15 MB |
| Processor cache type |
Smart Cache |
| Processor threads |
12 |
| Number of processors installed |
1 |
| Number of processors supported |
1 |
| Processor base power |
130 W |
| Maximum turbo power |
156 W |
| Memory |
| Internal memory |
32 GB |
| Maximum internal memory |
2 TB |
| Internal memory type |
DDR5-SDRAM |
| Memory layout (slots x size) |
2 x 16 GB |
| Memory slots |
4x DIMM |
| Memory clock speed |
4800 MHz |
| ECC |
Yes |
| Memory channels |
Single-channel |
| Buffered memory type |
Registered (buffered) |
| Ports & interfaces |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
5 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
5 |
| PowerShare |
Yes |
| Ethernet LAN (RJ-45) ports |
2 |
| Line-out |
Yes |
| Combo headphone/mic port |
Yes |
| Number of rear USB ports |
6 |
| Number of front USB ports |
4 |
| Number of front audio ports |
1 |
| Number of rear audio ports |
1 |
| Number of SATA III connectors |
4 |
| Power |
| Power supply |
750 W |
| Power supply input voltage |
90 - 264 V |
| Power supply input frequency |
47/63 Hz |
| Operational conditions |
| Operating temperature (T-T) |
10 - 35 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating altitude |
-15.2 - 3048 m |
| Non-operating altitude |
-15.2 - 10668 m |
| Operating vibration |
0.52 G |
| Non-operating vibration |
2 G |
| Operating shock |
40 G |
| Non-operating shock |
105 G |
| Weight & dimensions |
| Width |
176.5 mm |
| Depth |
452.1 mm |
| Height |
417.9 mm |
| Weight |
21.7 kg |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ethernet LAN data rates |
1000,10000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| Top Wi-Fi standard |
Not available |
| Bluetooth |
No |
| Operating system/software |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Operating system language |
German, Dutch, English, French, Italian |
| Trial software |
No Microsoft Office License Included 30 day Trial Offer Only |
| Software |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Operating system language |
German, Dutch, English, French, Italian |
| Trial software |
No Microsoft Office License Included 30 day Trial Offer Only |
| Storage |
| Total storage capacity |
1 TB |
| Optical drive type |
No |
| Storage media |
SSD |
| Card reader integrated |
Yes |
| Number of storage drives installed |
1 |
| Total SSDs capacity |
1 TB |
| Number of SSDs installed |
1 |
| SSD capacity |
1 TB |
| SSD interface |
PCI Express |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| SSD performance class |
40 |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| RAID support |
No |
| Expansion slots |
| PCI Express x8 (Gen 4.x) slots |
2 |
| PCI Express x16 (Gen 4.x) slots |
1 |
| PCI Express x16 (Gen 5.x) slots |
1 |
| Graphics |
| Discrete graphics card |
No |
| On-board graphics card |
No |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Not available |
| Discrete graphics memory type |
GDDR6 |
| Number of discrete graphics cards |
1 |
| Packaging content |
| Display included |
No |
| Mouse included on selected markets only |
Yes |
| Mouse connectivity |
Wired |
| Keyboard included on selected markets only |
Yes |
| Keyboard connectivity |
Wired |
| Input device model |
Dell Wired Keyboard-KB216 - UK (QWERTY) - Black,Dell Optical Mouse - MS116 - Black |
| Cables included |
AC |
| Design |
| Chassis type |
Tower |
| Product colour |
Black |
| Placement supported |
Horizontal/Vertical |
| Water cooling system |
No |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Intel® vPro™ Platform Eligibility |
Yes |
| Performance |
| Product type |
Workstation |
| Market positioning |
Business |
| Motherboard chipset |
Intel W790 |
| Audio chip |
Realtek ALC3246-CG |
| Built-in speaker(s) |
Yes |
| Number of speakers |
1 |
| Trusted Platform Module (TPM) |
Yes |
| Sustainability |
| Sustainability certificates |
ENERGY STAR, RoHS |
