| Processor |
| Processor family |
AMD Ryzen Threadripper PRO |
| Processor manufacturer |
AMD |
| Processor model |
7945WX |
| Processor frequency |
4.7 GHz |
| Processor generation |
AMD Ryzen Threadripper PRO 7000 WX-Series |
| Processor cores |
12 |
| Processor threads |
24 |
| Processor boost frequency |
5.3 GHz |
| Processor cache |
76 MB |
| Processor base power |
350 W |
| Memory |
| Internal memory |
64 GB |
| Maximum internal memory |
2 TB |
| Internal memory type |
DDR5-SDRAM |
| Memory layout (slots x size) |
2 x 32 GB |
| Memory slots |
8x DIMM |
| ECC |
Yes |
| Buffered memory type |
Registered (buffered) |
| Memory data transfer rate |
5200 MT/s |
| Ports & interfaces |
| USB 2.0 ports quantity |
0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
5 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
5 |
| Thunderbolt 3 ports quantity |
0 |
| HDMI ports quantity |
0 |
| PowerShare |
Yes |
| Ethernet LAN (RJ-45) ports |
2 |
| Line-out |
Yes |
| Combo headphone/mic port |
Yes |
| Number of rear USB ports |
6 |
| Number of front USB ports |
4 |
| Number of front audio ports |
1 |
| Power |
| Power supply |
1000 W |
| Power supply input voltage |
90 - 264 V |
| Power supply input frequency |
47/63 Hz |
| 80 PLUS certification |
80 PLUS Platinum |
| Operational conditions |
| Operating temperature (T-T) |
0 - 35 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating altitude |
-15.2 - 3048 m |
| Non-operating altitude |
-15.2 - 10668 m |
| Operating vibration |
0.52 G |
| Non-operating vibration |
2 G |
| Operating shock |
40 G |
| Non-operating shock |
105 G |
| Weight & dimensions |
| Width |
172.6 mm |
| Depth |
465 mm |
| Height |
442.7 mm |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ethernet LAN data rates |
10,100,1000,10000 Mbit/s |
| Operating system/software |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Operating system language |
German, Dutch, English, French, Italian |
| Trial software |
Activate Your Microsoft 365 For A 30 Day Trial |
| Software |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Operating system language |
German, Dutch, English, French, Italian |
| Trial software |
Activate Your Microsoft 365 For A 30 Day Trial |
| Storage |
| Total storage capacity |
2 TB |
| Optical drive type |
No |
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| Total SSDs capacity |
2 TB |
| Number of SSDs installed |
1 |
| SSD capacity |
2 TB |
| SSD interface |
PCI Express 4.0 |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| SSD performance class |
40 |
| Expansion slots |
| PCI Express x8 (Gen 4.x) slots |
3 |
| PCI Express x16 (Gen 4.x) slots |
1 |
| PCI Express x16 (Gen 5.x) slots |
1 |
| Graphics |
| Discrete graphics card |
No |
| On-board graphics card |
No |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Not available |
| Graphics card DisplayPorts quantity |
2 |
| Packaging content |
| Display included |
No |
| Mouse included on selected markets |
Dell Optical Mouse - MS116 - Black |
| Keyboard included on selected markets |
Dell Multimedia Keyboard-KB216 - UK (QWERTY) |
| Cables included |
AC |
| Design |
| Chassis type |
Tower |
| Product colour |
Black |
| Placement supported |
Vertical |
| Viewing window |
No |
| Performance |
| Product type |
PC |
| Market positioning |
Business |
| Audio chip |
Realtek ALC3246 |
| Trusted Platform Module (TPM) |
Yes |
| Sustainability |
| Sustainability certificates |
ENERGY STAR, EPEAT Gold |
| Sustainability compliance |
Yes |
| Carbon footprint |
| Total carbon footprint (kg of CO2e) |
1939 |
| Total carbon emissions, standard deviation (kg of CO2e) |
818 |
| Carbon emissions, manufacturing (kg of CO2e) |
584 |
| Carbon emissions, logistics (kg of CO2e) |
62 |
| Carbon emissions, energy usage (kg of CO2e) |
1279 |
| Carbon emissions, end-of-life (kg of CO2e) |
14 |
| Total carbon emissions, w/o use phase (kg of CO2e) |
661 |
| PAIA version |
1.3.2 |
