| Memory |
| Internal memory |
32 GB |
| Internal memory type |
DDR5-SDRAM |
| Maximum internal memory |
128 GB |
| Buffered memory type |
Unregistered (unbuffered) |
| Memory slots |
4x DIMM |
| ECC |
Yes |
| Memory layout (slots x size) |
1 x 32 GB |
| Memory data transfer rate |
5600 MT/s |
| Processor |
| Processor family |
Intel Xeon 6 |
| Processor manufacturer |
Intel |
| Processor model |
6315P |
| Processor frequency |
2.8 GHz |
| Processor boost frequency |
5.2 GHz |
| Performance cores |
4 |
| Processor cores |
4 |
| Processor cache |
12 MB |
| Number of processors installed |
1 |
| Thermal Design Power (TDP) |
55 W |
| System bus rate |
16 GT/s |
| Processor threads |
4 |
| Memory types supported by processor |
DDR5-SDRAM |
| Memory clock speeds supported by processor |
4800 MHz |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
2 |
| USB 2.0 ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| VGA (D-Sub) ports quantity |
1 |
| Serial ports quantity |
1 |
| Networking |
| LAN controller |
Broadcom 5720 |
| Ethernet LAN |
Yes |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet interface type |
Gigabit Ethernet |
| Weight & dimensions |
| Width |
132.5 mm |
| Height |
332.5 mm |
| Power |
| Redundant power supply (RPS) support |
No |
| Power supply |
300 W |
| Number of main power supplies |
1 |
| Operational conditions |
| Storage temperature (T-T) |
-40 - 65 °C |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating altitude |
0 - 3048 m |
| Non-operating altitude |
0 - 12000 m |
| Packaging content |
| Packaging content |
European Power Cord 220V |
| Storage |
| Total storage capacity |
2 TB |
| RAID support |
No |
| Optical drive type |
No |
| Number of HDDs installed |
1 |
| HDD capacity |
2 TB |
| HDD interface |
SATA III |
| HDD speed |
7200 RPM |
| HDD size |
3.5" |
| Number of HDDs supported |
5 |
| Supported HDD sizes |
2.5,3.5" |
| Supported RAID controllers |
PERC H355 Adapter LP |
| Other features |
| Data transfer rate |
6 Gbit/s |
| Bytes per sector |
512n |
| Performance |
| Remote administration |
iDRAC9, Enterprise 16G |
| Design |
| Chassis type |
Tower (3U) |
| Product colour |
Black |
| Operating system/software |
| Operating system installed |
No |
| Compatible operating systems |
Canonical Ubuntu Server LTS
Microsoft Windows Server with Hyper-V
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
VMware ESXi |
| Software |
| Operating system installed |
No |
| Compatible operating systems |
Canonical Ubuntu Server LTS
Microsoft Windows Server with Hyper-V
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
VMware ESXi |
| Carbon footprint |
| Total carbon footprint (kg of CO2e) |
1182 |
| Total carbon emissions, standard deviation (kg of CO2e) |
924 |
| Carbon emissions, manufacturing (kg of CO2e) |
319.14 |
| Carbon emissions, logistics (kg of CO2e) |
130.02 |
| Carbon emissions, energy usage (kg of CO2e) |
709.2 |
| Carbon emissions, end-of-life (kg of CO2e) |
23.64 |
| PAIA version |
Not available |
