| Processor |
| Processor family |
Intel Core Ultra 5 |
| Processor manufacturer |
Intel |
| Processor model |
235T |
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor cores |
14 |
| Processor threads |
14 |
| Processor boost frequency |
5 GHz |
| Performance cores |
6 |
| Efficient cores |
8 |
| Performance-core Max Turbo Frequency |
5 GHz |
| Efficient-core Max Turbo Frequency |
4.4 GHz |
| Performance-core base frequency |
2.2 GHz |
| Efficient-core base frequency |
1.6 GHz |
| Processor cache |
24 MB |
| Processor cache type |
Smart Cache |
| Number of processors installed |
1 |
| Processor base power |
35 W |
| Maximum turbo power |
114 W |
| Memory |
| Internal memory |
16 GB |
| Maximum internal memory |
64 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory layout (slots x size) |
1 x 16 GB |
| Memory slots |
2x SO-DIMM |
| Non-ECC |
Yes |
| Memory channels |
Single-channel |
| Memory data transfer rate |
5600 MT/s |
| Ports & interfaces |
| USB 2.0 ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Thunderbolt 3 ports quantity |
0 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| DisplayPort version |
1.4a |
| HDMI version |
2.1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Combo headphone/mic port |
Yes |
| DC-in jack |
Yes |
| Number of rear USB ports |
4 |
| Number of front USB ports |
2 |
| Number of front audio ports |
1 |
| Power |
| Power supply |
90 W |
| Power supply input voltage |
100 - 240 V |
| Power supply input frequency |
50 / 60 Hz |
| Operational conditions |
| Operating temperature (T-T) |
10 - 35 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating altitude |
-15.2 - 3048 m |
| Non-operating altitude |
-15.2 - 10668 m |
| Operating vibration |
0.26 G |
| Non-operating vibration |
1.37 G |
| Operating shock |
40 G |
| Non-operating shock |
105 G |
| Weight & dimensions |
| Width |
36 mm |
| Depth |
178 mm |
| Height |
182 mm |
| Weight |
1.16 kg |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| LAN controller |
Intel WGI219LM |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer |
Intel |
| WLAN controller model |
Intel Wi-Fi 6E AX211 |
| Antenna type |
2x2 |
| Antenna design |
Internal |
| Bluetooth |
Yes |
| Operating system/software |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Trial software |
Activate Your Microsoft 365 For A 30 Day Trial |
| Software |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Trial software |
Activate Your Microsoft 365 For A 30 Day Trial |
| Storage |
| Total storage capacity |
512 GB |
| Optical drive type |
No |
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| Total SSDs capacity |
512 GB |
| Number of SSDs installed |
1 |
| SSD capacity |
512 GB |
| SSD interface |
PCI Express 4.0 |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| Graphics |
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel® Graphics |
| On-board GPU manufacturer |
Intel |
| On-board graphics card family |
Intel® Graphics |
| Packaging content |
| Mouse included on selected markets |
Dell Optical Mouse-MS116 - Black |
| Keyboard included on selected markets |
Dell Wired Keyboard - KB216 - UK (QWERTY) - Black |
| Design |
| Chassis type |
Micro PC |
| Product colour |
Black |
| Placement supported |
Horizontal/Vertical |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Intel® vPro™ Platform Eligibility |
Yes |
| Performance |
| Product type |
Mini PC |
| Market positioning |
Business |
| Motherboard chipset |
Intel® Q870 |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Sustainability |
| Sustainability certificates |
ENERGY STAR, EPEAT Climate +, EPEAT Gold |
| Carbon footprint |
| Total carbon footprint (kg of CO2e) |
77.6 |
| Carbon emissions, manufacturing (kg of CO2e) |
41.52 |
| Carbon emissions, logistics (kg of CO2e) |
2.17 |
| Carbon emissions, energy usage (kg of CO2e) |
33.45 |
| Carbon emissions, end-of-life (kg of CO2e) |
0.54 |
| PAIA version |
GaBi version 1, 2024 |
| Neural processor unit (NPU) |
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to |
27 TOPs |
| NPU performance up to |
13 TOPs |
| GPU performance up to |
6 TOPs |
| Display |
| Display included |
No |
| Audio |
| Audio chip |
Realtek ALC3204 |
| Audio system |
High Definition Audio |
