| Processor |
| Processor family |
Intel® Core™ i7 |
| Processor manufacturer |
Intel |
| Processor model |
i7-12700 |
| Processor generation |
12th gen Intel® Core™ i7 |
| Processor cores |
12 |
| Processor boost frequency |
4.9 GHz |
| Efficient-core base frequency |
1.6 GHz |
| Processor cache |
25 MB |
| Bus type |
DMI4 |
| Number of processors installed |
1 |
| Number of processors supported |
1 |
| Memory |
| Internal memory |
16 GB |
| Maximum internal memory |
128 GB |
| Internal memory type |
DDR4-SDRAM |
| Memory layout (slots x size) |
2 x 8 GB |
| Memory slots |
4x DIMM |
| Memory clock speed |
3200 MHz |
| Memory channels |
Dual-channel |
| Buffered memory type |
Unregistered (unbuffered) |
| Ports & interfaces |
| USB 2.0 ports quantity |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| USB 3.2 Gen 2x2 Type-C ports quantity |
1 |
| PowerShare |
Yes |
| DisplayPorts quantity |
3 |
| DisplayPort version |
1.4 |
| Ethernet LAN (RJ-45) ports |
1 |
| Line-out |
Yes |
| Line-in |
Yes |
| Combo headphone/mic port |
Yes |
| Number of rear USB ports |
6 |
| Number of front USB ports |
4 |
| Number of front audio ports |
1 |
| Number of rear audio ports |
1 |
| Number of SATA III connectors |
3 |
| Power |
| Power supply |
260 W |
| Power supply input voltage |
90 - 264 V |
| Power supply input frequency |
47 - 63 Hz |
| 80 PLUS certification |
80 PLUS Bronze |
| Operational conditions |
| Operating temperature (T-T) |
10 - 35 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
5 - 95% |
| Operating altitude |
-15.2 - 3048 m |
| Non-operating altitude |
-15.2 - 10668 m |
| Operating vibration |
0.26 G |
| Non-operating vibration |
1.37 G |
| Non-operating shock |
105 G |
| Weight & dimensions |
| Width |
92.6 mm |
| Depth |
292.8 mm |
| Height |
290 mm |
| Weight |
5.3 kg |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Ethernet LAN data rates |
10,1000,100 Mbit/s |
| Cabling technology |
10/100/1000Base-T(X) |
| Bluetooth |
No |
| Operating system/software |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Operating system language |
Multilingual |
| Trial software |
No Microsoft Office License Included 30 day |
| Software |
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Operating system language |
Multilingual |
| Trial software |
No Microsoft Office License Included 30 day |
| Storage |
| Total storage capacity |
512 GB |
| Optical drive type |
DVD±RW |
| Storage media |
SSD |
| Number of storage drives installed |
1 |
| Total SSDs capacity |
512 GB |
| Number of SSDs installed |
1 |
| SSD capacity |
512 GB |
| SSD interface |
NVMe, PCI Express |
| NVMe |
Yes |
| SSD form factor |
M.2 |
| SSD performance class |
35 |
| Compatible memory cards |
Not supported |
| RAID support |
No |
| Expansion slots |
| PCI Express x1 slots |
0 |
| PCI Express x4 (Gen 3.x) slots |
1 |
| PCI Express x16 slots |
1 |
| PCI Express x16 (Gen 4.x) slots |
1 |
| PCI slots |
0 |
| Graphics |
| Discrete graphics card |
No |
| On-board graphics card |
Yes |
| Discrete graphics card model |
Not available |
| On-board graphics card model |
Intel UHD Graphics 770 |
| On-board GPU manufacturer |
Intel |
| Maximum on-board graphics card resolution |
7680 x 4320 pixels |
| Packaging content |
| Mouse included on selected markets only |
Yes |
| Mouse connectivity |
Wireless |
| Keyboard included on selected markets only |
Yes |
| Keyboard connectivity |
Wireless |
| Input device model |
KM5221W |
| Cables included |
AC |
| Processor special features |
| Intel 64 |
Yes |
| Enhanced Intel SpeedStep Technology |
Yes |
| Embedded options available |
No |
| Intel VT-x with Extended Page Tables (EPT) |
Yes |
| Idle States |
Yes |
| Intel Stable Image Platform Program (SIPP) |
Yes |
| Intel Trusted Execution Technology |
Yes |
| Execute Disable Bit |
Yes |
| CPU configuration (max) |
1 |
| Intel Virtualization Technology for Directed I/O (VT-d) |
Yes |
| Intel Virtualization Technology (VT-x) |
Yes |
| Design |
| Chassis type |
SFF |
| Product colour |
Black |
| Placement supported |
Horizontal/Vertical |
| Water cooling system |
No |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Intel® vPro™ Platform Eligibility |
Yes |
| Performance |
| Product type |
PC |
| Market positioning |
Business |
| Motherboard chipset |
Intel Q670 |
| Audio chip |
Realtek ALC3246-CG |
| Audio system |
High Definition Audio |
| Audio output channels |
4.0 channels |
| Built-in speaker(s) |
No |
| Trusted Platform Module (TPM) |
Yes |
| Logistics data |
| Harmonized System (HS) code |
84715000 |
| Carbon footprint |
| Total carbon footprint (kg of CO2e) |
343 |
| Total carbon emissions, standard deviation (kg of CO2e) |
85 |
| Carbon emissions, manufacturing (kg of CO2e) |
229 |
| Carbon emissions, logistics (kg of CO2e) |
16 |
| Carbon emissions, energy usage (kg of CO2e) |
95 |
| Carbon emissions, end-of-life (kg of CO2e) |
4 |
| Total carbon emissions, w/o use phase (kg of CO2e) |
248 |
| PAIA version |
1.3.1, 2022 |
| Display |
| Display included |
No |
