| Weight & dimensions |
| Weight |
24.3 kg |
| Width |
586 mm |
| Depth |
492 mm |
| Height |
218 mm |
| Package weight |
0 g |
| Operational conditions |
| Storage temperature (T-T) |
-10 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Projector |
| Projector brightness |
16000 ANSI lumens |
| Projection technology |
3LCD |
| Projector native resolution |
WUXGA (1920x1200) |
| Contrast ratio (typical) |
2000:1 |
| Native aspect ratio |
16:10 |
| Smart projector |
No |
| Number of colours |
1.07 billion colours |
| Projector brightness (economic mode) |
11200 ANSI lumens |
| Keystone correction, horizontal |
18° |
| Keystone correction, vertical |
60° |
| Matrix size |
2.62 cm (1.03") |
| White light output |
16000 ANSI lumens |
| Colour light output |
16000 ANSI lumens |
| Heat dissipation |
3682 BTU/h |
| Video |
| Full HD |
Yes |
| 3D |
No |
| Video processing |
10 bit |
| Video colour modes |
Cinema, Dynamic, Natural, Presentation, DICOM simulation mode, Multi-projection, BT.709 |
| Display |
| Built-in display |
No |
| Lens system |
| Focus |
Auto |
| Focal length range |
varies by lens |
| Zoom capability |
Yes |
| Zoom type |
Auto |
| Zoom ratio |
1.6:1 |
| Throw ratio |
0.35 - 7.41:1 |
| Vertical lens shift range |
-60 - 60% |
| Lens position memory |
10 |
| Interchangeable lens |
Yes |
| Power |
| Power source |
AC |
| Power consumption (typical) |
1083 W |
| Power consumption (standby) |
0.4 W |
| Power consumption (economy mode) |
773 W |
| AC input voltage |
200-240 V |
| AC input frequency |
50 - 60 Hz |
| Ports & interfaces |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
1 |
| DVI port |
Yes |
| Serial interface type |
RS-232C |
| HDBaseT port |
Yes |
| Service port type |
USB Type-B |
| USB 2.0 ports quantity |
2 |
| USB 2.0 Type-A ports quantity |
2 |
| AC (power) in |
Yes |
| Networking |
| Smart TV |
No |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Storage |
| Card reader integrated |
No |
| Packaging content |
| Remote control included |
Yes |
| Batteries included |
Yes |
| Cables included |
AC |
| Manual |
Yes |
| Warranty card |
Yes |
| WLAN adapter included |
Yes |
| Packaging content |
Cable cover, Lens connector cap, Power cable, Remote control incl. batteries, User manual, Warranty document |
| Bundled software |
Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Content Manager, Epson Projektor Management, Epson Projektor Professional Tool |
| Other features |
| Supported network protocols |
HTTPS, IPv6, SNMP, ESC/VP.net, PJLink |
| Design |
| Product type |
Large venue projector |
| Product colour |
White |
| Placement |
Ceiling, Desktop, Flying frame |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Multimedia |
| Built-in speaker(s) |
No |
| Software |
| Software support |
via: AMX, Crestron (Network), Extron |
| Features |
| Noise level |
38 dB |
| Interactive |
No |
| Noise level (economic mode) |
34 dB |
| Projection modes |
Ceiling |
| On Screen Display (OSD) |
Yes |
| Country of origin |
China |
| High Dynamic Range (HDR) supported |
Yes |
| Password protection |
Yes |
| Light source |
| Light source type |
Laser |
| Service life of light source |
20000 h |
| Service life of light source (economic mode) |
30000 h |
| Light source brightness |
16000 lm |
| Logistics data |
| Quantity per pack |
1 pc(s) |
| Harmonized System (HS) code |
85286200 |
