| Weight & dimensions |
| Weight |
7.7 kg |
| Width |
440 mm |
| Depth |
122 mm |
| Height |
304 mm |
| Package width |
540 mm |
| Package depth |
530 mm |
| Package height |
210 mm |
| Package weight |
10.4 kg |
| Operational conditions |
| Storage temperature (T-T) |
-10 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Projector |
| Projector brightness |
5200 ANSI lumens |
| Projection technology |
3LCD |
| Projector native resolution |
WUXGA (1920x1200) |
| Contrast ratio (typical) |
2500000:1 |
| Native aspect ratio |
16:10 |
| Screen size compatibility |
1270 - 12700 mm (50 - 500") |
| Number of colours |
1.07 billion colours |
| Projector brightness (economic mode) |
3640 ANSI lumens |
| Vertical scan range |
192 - 240 Hz |
| Keystone correction, horizontal |
-30 - 30° |
| Keystone correction, vertical |
-30 - 30° |
| Matrix size |
1.7 cm (0.67") |
| Video |
| Analog signal format system |
Not supported |
| Full HD |
Yes |
| 3D |
No |
| Video processing |
10 bit |
| Video colour modes |
Cinema, Dynamic, Presentation, sRGB, DICOM simulation mode |
| Display |
| Built-in display |
No |
| Lens system |
| Focus |
Manual |
| Focal length range |
20 - 31.8 mm |
| Aperture range (F-F) |
1.5 - 1.7 |
| Zoom capability |
Yes |
| Zoom type |
Manual |
| Zoom ratio |
1.6:1 |
| Throw ratio |
1.35 - 2.2:1 |
| Power |
| Power source |
AC |
| Power consumption (typical) |
293 W |
| Power consumption (standby) |
0.3 W |
| Power consumption (economy mode) |
223 W |
| AC input voltage |
100-240 V |
| AC input frequency |
50 - 60 Hz |
| Ports & interfaces |
| VGA (D-Sub) ports quantity |
3 |
| HDMI ports quantity |
2 |
| DVI port |
No |
| USB 2.0 ports quantity |
2 |
| Audio (L/R) in |
1 |
| Serial interface type |
RS-232C |
| USB 2.0 Type-B ports quantity |
1 |
| Networking |
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, Wi-Fi 4 (802.11n) |
| Storage |
| Card reader integrated |
No |
| Packaging content |
| Remote control included |
Yes |
| Batteries included |
Yes |
| Cables included |
AC, HDMI |
| Warranty card |
Yes |
| Bundled software |
EasyMP Multi PC Projection |
| Design |
| Product type |
Standard throw projector |
| Market positioning |
Presentation |
| Product colour |
White |
| Placement |
Ceiling, Desktop, Floor, Wall |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Multimedia |
| Built-in speaker(s) |
Yes |
| RMS rated power |
10 W |
| Number of built-in speakers |
1 |
| Technical details |
| Sustainability certificates |
TCO |
| USB display function |
3 in 1: Image / Mouse / Sound |
| Software |
| Software support |
via: AMX, Crestron (Network), Control4, Crestron Integrated Partner, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol |
| Features |
| Noise level |
31 dB |
| Noise level (economic mode) |
23 dB |
| Country of origin |
Philippines |
| Light source |
| Light source type |
Laser |
| Service life of light source |
20000 h |
| Service life of light source (economic mode) |
30000 h |
| Logistics data |
| Quantity per pack |
1 pc(s) |
| Products per pallet |
14 pc(s) |
| Products per pallet (UK) |
14 pc(s) |
| Harmonized System (HS) code |
85286200 |
