| Weight & dimensions |
| Weight |
2.7 kg |
| Width |
302 mm |
| Depth |
249 mm |
| Height |
87 mm |
| Package width |
350 mm |
| Package depth |
380 mm |
| Package height |
160 mm |
| Package weight |
4.01 kg |
| Operational conditions |
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
-10 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage relative humidity (H-H) |
10 - 90% |
| Projector |
| Projector brightness |
3800 ANSI lumens |
| Projection technology |
3LCD |
| Projector native resolution |
WXGA (1280x800) |
| Contrast ratio (typical) |
16000:1 |
| Native aspect ratio |
16:10 |
| Screen size compatibility |
838.2 - 8128 mm (33 - 320") |
| Supported aspect ratios |
16:10 |
| Number of colours |
1.07 billion colours |
| Projector brightness (economic mode) |
2600 ANSI lumens |
| Vertical scan range |
100 - 120 Hz |
| Keystone correction, horizontal |
-30 - 30° |
| Keystone correction, vertical |
-30 - 30° |
| Matrix size |
1.5 cm (0.59") |
| Video |
| Full HD |
No |
| 3D |
No |
| Video processing |
10 bit |
| Video colour modes |
Dynamic, Cinema, Presentation, sRGB, Blackboard |
| Display |
| Built-in display |
No |
| Lens system |
| Focus |
Manual |
| Focal length range |
16.9 - 20.28 mm |
| Aperture range (F-F) |
1.49 - 1.72 |
| Zoom capability |
Yes |
| Zoom type |
Manual |
| Zoom ratio |
1.2:1 |
| Throw ratio |
1.30 - 1.56:1 |
| Power |
| Power source |
AC |
| Power consumption (typical) |
327 W |
| Power consumption (standby) |
0.3 W |
| Power consumption (economy mode) |
225 W |
| AC input voltage |
100-240 V |
| AC input frequency |
50 - 60 Hz |
| Ports & interfaces |
| VGA (D-Sub) ports quantity |
3 |
| HDMI ports quantity |
2 |
| Composite video in |
1 |
| Component video (YPbPr/YCbCr) in |
0 |
| DVI port |
No |
| Audio (L/R) in |
0 |
| Serial interface type |
RS-232C |
| HDMI connector type |
Full-size |
| S-Video inputs quantity |
0 |
| USB 2.0 ports quantity |
1 |
| USB 2.0 Type-B ports quantity |
1 |
| PC Audio in |
Yes |
| PC Audio out |
Yes |
| PC in (D-Sub) |
Yes |
| AC (power) in |
Yes |
| Networking |
| Smart TV |
No |
| Ethernet LAN |
Yes |
| Ethernet LAN (RJ-45) ports |
1 |
| Storage |
| Card reader integrated |
No |
| Packaging content |
| Remote control included |
Yes |
| Batteries included |
Yes |
| Cables included |
AC, HDMI |
| WLAN adapter included |
Yes |
| Bundled software |
EasyMP Network Projection, Epson Projektor Management |
| Other features |
| Supported network protocols |
PJLink |
| Design |
| Product type |
Standard throw projector |
| Market positioning |
Portable |
| Product colour |
White |
| Placement |
Ceiling, Desktop |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Multimedia |
| Built-in speaker(s) |
Yes |
| RMS rated power |
5 W |
| Number of built-in speakers |
1 |
| Technical details |
| USB display function |
3 in 1: Image / Mouse / Sound |
| Software |
| Software support |
via: AMX, Crestron (Network), Control4, Extron |
| Features |
| Noise level |
37 dB |
| Noise level (economic mode) |
28 dB |
| Noise level (standby) |
28 dB |
| Preset modes |
Blackboard, Dynamic, Presentation, Theatre, sRGB |
| On Screen Display (OSD) |
Yes |
| Country of origin |
Philippines |
| Light source |
| Light source type |
Lamp |
| Service life of light source |
8000 h |
| Service life of light source (economic mode) |
17000 h |
| Lamp type |
UHE |
| Lamp power |
210 W |
| Lamps quantity |
1 lamp(s) |
| Logistics data |
| Quantity per pack |
1 pc(s) |
| Products per pallet |
78 pc(s) |
| Pallet gross weight |
0 g |
| Products per pallet (UK) |
78 pc(s) |
| Pallet weight (UK) |
0 g |
| Harmonized System (HS) code |
85286200 |
