| Image sensor |
| Sensor type |
CMOS |
| Optical sensor size |
25.4 / 2.8 mm (1 / 2.8") |
| Progressive scan |
Yes |
| Lens system |
| Maximum aperture number |
2 |
| Fixed focal length |
2.8 mm |
| Camera |
| Minimum illumination |
0 lx |
| Lens viewing angle, horizontal |
110° |
| Lens viewing angle, vertical |
58° |
| Lens viewing angle, diagonal |
131° |
| Video |
| Maximum resolution |
2304 x 1296 pixels |
| Total megapixels |
3 MP |
| Video formats supported |
H.264, H.265 |
| Video compression formats |
H.264, H.265 |
| Supported graphics resolutions |
2304 x 1296 |
| Noise reduction |
Yes |
| Noise reduction technology |
3D noise reduction |
| Bit rate |
1.5 Mbps |
| Audio |
| Built-in speaker(s) |
Yes |
| Audio system |
2-way |
| Built-in microphone |
Yes |
| Networking |
| Ethernet LAN |
No |
| Wi-Fi |
Yes |
| Bluetooth |
No |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Wi-Fi data rate (max) |
72 Mbit/s |
| Channel bandwidth |
20 MHz |
| Security |
| Password protection |
Yes |
| Video motion detection |
Yes |
| Security algorithms |
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Motion sensor |
Yes |
| Motion sensor technology |
Passive infrared (PIR) sensor |
| Anti-flicker |
Yes |
| Heartbeat |
Yes |
| Digital watermark |
Yes |
| Power |
| Power source type |
Battery |
| Power consumption (max) |
10 W |
| DC output voltage |
5 |
| DC output current |
2 A |
| Battery capacity |
5200 mAh |
| Operational conditions |
| Operating temperature (T-T) |
-20 - 50 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Weight & dimensions |
| Depth |
62.8 mm |
| Height |
62.8 mm |
| Length |
105.9 mm |
| Weight |
522 g |
| Management features |
| Reset button |
Yes |
| Packaging content |
| Number of cameras |
1 |
| Cables included |
USB |
| Mounting brackets included |
Yes |
| Screws included |
Yes |
| Drilling template included |
Yes |
| Manual |
Yes |
| Night vision |
| Night vision |
Yes |
| B/W night vision distance |
15 m |
| Colour night vision distance |
15 m |
| LED type |
IR |
| Storage |
| Built-in HDD |
No |
| Card reader integrated |
Yes |
| Compatible memory cards |
MicroSD (TransFlash) |
| Maximum memory card size |
256 GB |
| Design |
| Mounting type |
Wall |
| Product colour |
Black |
| Form factor |
Bullet |
| Weatherproof |
Yes |
| Performance |
| Type |
IP security camera |
| Placement supported |
Outdoor |
| Connectivity technology |
Wireless |
| Day/night mode |
Yes |
| Infrared (IR) cut-off filter |
Yes |
| Built-in light |
Yes |
| Operating frequency |
2400 - 2.4835 MHz |
| Packaging data |
| Package width |
103 mm |
| Package depth |
186 mm |
| Package height |
103 mm |
| Sustainability |
| Compliance certificates |
CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA, WEEE |
| Sustainability compliance |
Yes |
