| Weight & dimensions |
| Width |
226 mm |
| Depth |
185 mm |
| Height |
35 mm |
| Memory |
| Supported memory types |
DDR4-SDRAM |
| Number of memory slots |
2 |
| Maximum internal memory |
64 GB |
| Memory slots type |
DIMM |
| Memory channels |
Dual-channel |
| ECC сompatibility |
ECC & Non-ECC |
| Supported memory clock speeds |
2133,2400,2666,2933,3000,3200 MHz |
| Unbuffered memory |
Yes |
| Processor |
| Processor manufacturer |
Intel |
| Processor socket |
LGA 1200 (Socket H5) |
| Compatible processor series |
Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® |
| Supported processor sockets |
LGA 1200 (Socket H5) |
| Back panel I/O ports |
| USB 2.0 ports quantity |
4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
0 |
| Ethernet LAN (RJ-45) ports |
1 |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
1 |
| DVI-D ports quantity |
0 |
| PS/2 ports quantity |
2 |
| HDMI version |
1.4 |
| Microphone in |
Yes |
| USB connector type |
USB Type-A |
| Internal I/O |
| USB 2.0 connectors |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors |
1 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors |
0 |
| Number of SATA III connectors |
4 |
| Front panel audio connector |
Yes |
| Front panel connector |
Yes |
| ATX Power connector (24-pin) |
Yes |
| CPU fan connector |
Yes |
| Number of chassis fan connectors |
2 |
| EPS power connector (8-pin) |
Yes |
| TPM connector |
Yes |
| Serial port headers |
1 |
| 12V power connector |
Yes |
| RGB LED pin header |
Yes |
| Networking |
| Wi-Fi |
No |
| Ethernet LAN |
Yes |
| Ethernet interface type |
Gigabit Ethernet |
| Expansion slots |
| PCI Express x1 slots |
2 |
| PCI Express x16 slots |
1 |
| Number of M.2 (M) slots |
1 |
| Packaging content |
| Cables included |
SATA |
| Batteries included |
Yes |
| Drivers included |
Yes |
| BIOS |
| BIOS type |
UEFI AMI |
| BIOS memory size |
128 Mbit |
| ACPI version |
5.0 |
| Clear CMOS jumper |
Yes |
| Desktop Management Interface (DMI) version |
2.7 |
| System Management BIOS (SMBIOS) version |
2.7 |
| Graphics |
| Parallel processing technology support |
Not supported |
| Maximum resolution |
4096 x 2304 pixels |
| HDCP |
Yes |
| DirectX version |
12.0 |
| Number of displays supported |
2 |
| Technical details |
| Warranty period |
3 year(s) |
| Features |
| Component for |
PC |
| Motherboard form factor |
micro ATX |
| Motherboard chipset family |
Intel |
| Motherboard chipset |
Intel H510 Express |
| Audio output channels |
7.1 channels |
| Product colour |
Brown |
| PC health monitoring |
Fan, Temperature, Voltage |
| Windows operating systems supported |
Windows 10 x64 |
| Storage controllers |
| Supported storage drive interfaces |
M.2, PCI Express 3.0, SATA III |
| Supported storage drive types |
HDD & SSD |
| Number of storage drives supported |
5 |
| Logistics data |
| Country of origin |
China |
| Products per shipping (inner) case |
1 pc(s) |
| Battery |
| Battery weight |
3 g |
| Lithium weight per battery |
0.07 g |
| Number of battery cells |
1 |
| Battery technology |
Lithium-Manganese Dioxide (LiMnO2) |
| Battery type |
CR2032 |
| Packaging data |
| Package width |
265 mm |
| Package depth |
235 mm |
| Package height |
52 mm |
| Package weight |
756 g |
