| Video |
| HD type |
4K Ultra HD |
| Maximum video resolution |
3840 x 2160 pixels |
| Supported graphics resolutions |
640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 3840 x 2160 |
| Aspect ratio |
16:9 |
| Resolution at capture speed |
640x480@25fps, 640x480@30fps, 1280x720@25fps, 1280x720@30fps, 1920x1080@25fps, 1920x1080@30fps, 3840x2160@30fps |
| Audio |
| Built-in speaker(s) |
Yes |
| Number of speakers |
1 |
| Frequency range |
150 - 16000 Hz |
| Output voltage Total Harmonic Distortion (THD) |
4% |
| Automatic gain control |
Yes |
| Microphone pick-up range |
2.5 m |
| Operational conditions |
| Operating temperature (T-T) |
-10 - 50 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-10 - 60 °C |
| Storage relative humidity (H-H) |
20 - 90% |
| Weight & dimensions |
| Interface module dimensions (W x D x H) |
170 x 170 x 41.3 mm |
| Interface module weight |
750 g |
| Speaker dimensions (WxDxH) |
120 x 120 x 35.2 mm |
| Speaker weight |
395 g |
| Camera dimensions (WxDxH) |
220 x 93.75 x 56.5 mm |
| Ports & interfaces |
| USB connector type |
USB Type-A, USB Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity |
1 |
| Networking |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Networking standards |
IEEE 802.1Q, IEEE 802.1p |
| Supported network protocols |
TCP/IP (IPv4) |
| Quality of Service (QoS) support |
Yes |
| VLAN support |
Yes |
| Security algorithms |
256-bit AES, 802.1x RADIUS, SRTP, TLS |
| Power |
| Power source type |
DC |
| Current |
3 A |
| DC input voltage |
12 V |
| Display |
| Built-in display |
Yes |
| Display diagonal |
20.3 cm (8") |
| Display resolution |
1280 x 800 pixels |
| Touchscreen |
Yes |
| Camera |
| Megapixel (approx.) |
8.28 MP |
| Sensor type |
CCD |
| Image sensor size |
1/2.5" |
| Camera type |
Single camera |
| Zoom capability |
Yes |
| Digital zoom |
10x |
| Focal length range |
2.26 mm |
| Horizontal field of view |
100° |
| Vertical field of view |
64° |
| Diagonal field of view |
102° |
| 3D NR (Noise Reduction) |
Yes |
| Minimum illumination |
0.1 lx |
| Microphone |
| Microphone colour |
Black |
| Microphone sensitivity |
38 dB |
| Microphone frequency |
150 - 8000 Hz |
| Sound pressure level (max) |
65 dB |
| Number of microphone arrays |
6 |
| Interface module |
| Interface module HDMI ports quantity |
3 |
| Interface module HDMI input ports quantity |
1 |
| Interface module HDMI output ports quantity |
2 |
| Features |
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Computer system |
| Computer system type |
Mini PC |
| Processor family |
Qualcomm Snapdragon |
| Processor model |
QCS8250 |
| Operating system installed |
Android |
| Performance |
| Product type |
Group video conferencing system |
| Number of persons |
10 person(s) |
| Product colour |
Black |
| Number of cameras |
1 |
| Bluetooth |
Yes |
| Bluetooth version |
5.1 |
| Signal-to-Noise Ratio (SNR) |
75 dB |
| PTZ control |
Yes |
