Processor |
Processor family |
10th gen Intel® Core™ i7 |
Processor manufacturer |
Intel |
Processor model |
i7-10700F |
Processor cores |
8 |
Processor frequency |
2.9 GHz |
Processor boost frequency |
4.8 GHz |
Processor socket |
LGA 1200 (Socket H5) |
Processor cache |
16 MB |
Processor cache type |
L3 |
Processor threads |
16 |
System bus rate |
8 GT/s |
Processor lithography |
14 nm |
Processor operating modes |
64-bit |
Processor codename |
Comet Lake |
Thermal Design Power (TDP) |
65 W |
Tjunction |
100 °C |
PCI Express slots version |
3.0 |
Maximum number of PCI Express lanes |
16 |
PCI Express configurations |
1x16,2x8,1x8+2x4 |
Number of processors installed |
1 |
Maximum internal memory supported by processor |
128 GB |
Memory types supported by processor |
DDR4-SDRAM |
Memory clock speeds supported by processor |
2933 MHz |
Memory bandwidth supported by processor (max) |
45.8 GB/s |
Memory |
Internal memory |
16 GB |
Internal memory type |
DDR4-SDRAM |
Memory layout (slots x size) |
2 x 8 GB |
Memory slots |
4x DIMM |
Memory clock speed |
2933 MHz |
ECC |
N |
Internal memory manufacturer |
HyperX |
Ports & interfaces |
USB 2.0 ports quantity |
2 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
Ethernet LAN (RJ-45) ports |
1 |
Microphone in |
Y |
Line-out |
Y |
Line-in |
Y |
Combo headphone/mic port |
Y |
M.2 card slot (storage) |
3 |
Headphone outputs |
1 |
Power |
Power supply |
500 W |
Weight & dimensions |
Width |
165 mm |
Depth |
369 mm |
Height |
433 mm |
Weight |
11.5 kg |
Package width |
480 mm |
Package depth |
299 mm |
Package height |
542 mm |
Package weight |
14.6 kg |
Networking |
Ethernet LAN |
Y |
Wi-Fi |
Y |
Ethernet LAN data rates |
10,100,1000 Mbit/s |
Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
Wi-Fi standards |
Wi-Fi 6 (802.11ax) |
WLAN controller model |
Intel Wi-Fi 6 AX201 |
Antenna type |
2x2 |
Bluetooth |
Y |
Bluetooth version |
5.0 |
Miracast |
Y |
MU-MIMO |
Y |
WLAN controller manufacturer |
Intel |
Cabling technology |
10/100/1000Base-T(X) |
Operating system/software |
Operating system installed |
Windows 10 Home Advanced |
Pre-installed software |
Alexa; Netflix; ExpressVPN; LastPass Premium |
Trial software |
McAfee LiveSafe, Microsoft Office 365 |
Bundled software |
Dropbox |
Software |
Operating system installed |
Windows 10 Home Advanced |
Pre-installed software |
Alexa; Netflix; ExpressVPN; LastPass Premium |
Trial software |
McAfee LiveSafe, Microsoft Office 365 |
Bundled software |
Dropbox |
Storage |
Total storage capacity |
2256 GB |
Optical drive type |
N |
Card reader integrated |
N |
Storage media |
HDD+SSD |
Number of storage drives installed |
2 |
Total HDDs capacity |
2000 GB |
Number of HDDs installed |
1 |
HDD capacity |
2000 GB |
HDD interface |
SATA |
HDD speed |
7200 RPM |
Total SSDs capacity |
256 GB |
Number of SSDs installed |
1 |
SSD capacity |
256 GB |
SSD interface |
PCI Express,NVMe |
SSD form factor |
M.2 |
Expansion slots |
PCI Express x1 slots |
1 |
PCI Express x16 slots |
1 |
Graphics |
Discrete graphics adapter |
Y |
On-board graphics adapter |
N |
Discrete graphics adapter model |
NVIDIA® GeForce RTX™ 2060 |
On-board graphics adapter model |
Not available |
Discrete GPU manufacturer |
NVIDIA |
Discrete graphics memory type |
GDDR6 |
Discrete graphics adapter memory |
6 GB |
Number of discrete graphics adapters |
1 |
Graphics adapter HDMI ports quantity |
1 |
Graphics adapter DisplayPorts quantity |
1 |
Graphics adapter USB Type-C ports quantity |
1 |
Packaging content |
Display included |
N |
Processor special features |
Intel 64 |
Y |
Enhanced Intel SpeedStep Technology |
Y |
Embedded options available |
N |
Intel VT-x with Extended Page Tables (EPT) |
Y |
Idle States |
Y |
Thermal Monitoring Technologies |
Y |
Intel Stable Image Platform Program (SIPP) |
N |
Intel® AES New Instructions (Intel® AES-NI) |
Y |
Intel® Secure Key |
Y |
Intel® OS Guard |
Y |
Intel Trusted Execution Technology |
N |
Execute Disable Bit |
Y |
Intel Software Guard Extensions (Intel SGX) |
Y |
Processor package size |
37.5 x 37.5 mm |
Supported instruction sets |
SSE4.1,SSE4.2,AVX 2.0 |
Scalability |
1S |
CPU configuration (max) |
1 |
Thermal solution specification |
PCG 2015C |
Intel Virtualization Technology for Directed I/O (VT-d) |
Y |
Intel Virtualization Technology (VT-x) |
Y |
Processor ARK ID |
199318 |
Intel® Turbo Boost Technology |
2.0 |
Intel® Hyper Threading Technology (Intel® HT Technology) |
Y |
Intel® Identity Protection Technology (Intel® IPT) |
Y |
Intel® vPro™ Platform Eligibility |
N |
Design |
Chassis type |
Tower |
Product colour |
Black |
Placement supported |
Vertical |
Number of 3.5" bays |
2 |
Cable lock slot |
Y |
Cable lock slot type |
Kensington |
Country of origin |
China |
Performance |
Product type |
PC |
Market positioning |
Gaming |
Motherboard chipset |
Intel H470 |
Motherboard form factor |
micro ATX |
Audio system |
DTS Headphone:X |
Audio output channels |
5.1 channels |
Brand-specific features |
HP OMEN Command Center |
Y |
HP Support Assistant |
Y |
HP Software provided |
HP Audio Switch |
HP segment |
Home |
